Home /Products/Variable Frequency Drives VFD/ABB 1SFA896107R7000 softstarter PSR16-600-70 has a rated maximum operational current of 16 A with an operating voltage span from 208...600 V

ABB 1SFA896107R7000 softstarter PSR16-600-70 has a rated maximum operational current of 16 A with an operating voltage span from 208...600 V

1
MOQ
Negotiable
Price
ABB 1SFA896107R7000 softstarter PSR16-600-70 has a rated maximum operational current of 16 A with an operating voltage span from 208...600 V
Features Gallery Product Description Chat Now
Features
Specifications
Protection Class: IP20 To IP54
Mounting Type: Wall-mounted, Panel-mounted
Power Rating: 0.5 KW To 500 KW
Cooling Method: Forced Air Cooling
Display Type: LCD Or LED
Input Voltage: 200-480V AC
Braking Method: Dynamic Braking, Regenerative Braking
Communication Protocols: Modbus, Profibus, Ethernet/IP
Harmonic Mitigation: Built-in DC Choke Or External Filter
Operating Temperature Range: -10°C To 50°C
Output Voltage: 0-480V AC
Output Frequency: 0-400 Hz
Acceleration/Deceleration Time: 0.1 To 6000 Seconds
Control Method: V/F Control, Vector Control, Sensorless Vector Control
Overload Capacity: 150% For 1 Minute
Highlight:

ABB PSR16 softstarter 16A

,

softstarter 208-600V operating voltage

,

ABB PSR16-600-70 VFD
Basic Infomation
Place of Origin: china
Brand Name: ABB
Model Number: 1SFA896107R7000
Document: Softstarter_panorama_PSTrev...vF.pdf
Payment & Shipping Terms
Packaging Details: PIECES
Delivery Time: 5-8DAYS
Payment Terms: T/T
Product Description
ABB PSR16-600-70 Softstarter
Rated maximum operational current: 16 A | Operating voltage: 208-600 V
Product Overview
The ABB 1SFA896107R7000 PSR16-600-70 softstarter provides reliable motor starting and stopping control with voltage ramp functionality for industrial applications.
Ordering Information
Minimum Order Quantity: 1 piece
Customs Tariff Number: 85371091
Technical Documentation
  • Data Sheet: Softstarter main catalog
  • Instructions and Manuals: Softstarter PSR3 ... PSR16 for 100-240V
  • Technical Handbook: Softstarter Handbook
  • CAD Dimensional Drawing: 2D and 3D files for CAD systems
  • EPLAN Data: EPLAN EDZ PSR16
Physical Dimensions
Dimension Value
Width 45 mm
Height 140 mm
Depth/Length 114 mm
Weight 0.4 kg
Electrical Specifications
Parameter Specification
Rated Operational Voltage 208-600 V AC
Rated Control Supply Voltage 100-240 V AC
Rated Control Circuit Voltage 24 V DC
Rated Frequency 50/60 Hz
Rated Operational Current 16 A
Starting Capacity 4xIe for 6s
Ramp Time 0-20 seconds / 1-10 seconds
Power Ratings
Voltage Power Rating
230 V 4 kW
400 V 7.5 kW
500 V 7.5 kW
UL/CSA Specifications
Voltage Range Horsepower Rating
200-208 V AC 3 Hp
220-240 V AC 5 Hp
440-480 V AC 10 Hp
550-600 V AC 10 Hp
Environmental Conditions
Operating Temperature: -25°C to +60°C
Storage Temperature: -40°C to +70°C
Degree of Protection: IP20 (Main Terminals)
Compliance & Certifications
  • Conflict Minerals Reporting Template (CMRT)
  • REACH Declaration for all Softstarters
  • RoHS II Declaration (EU Directive 2011/65/EU)
  • Toxic Substances Control Act (TSCA) declaration
  • WEEE Category 5 - Business To Business
