MOOG SM2315D-DE Servo Motor With 10,786 RPM Speed IP65 Protection Industrial Automation

MOOG SM2315D‑DE Servo Motor

1. Product Overview

MOOG SM2315D‑DE is a fully‑integrated SmartMotor™ brushless DC servo motor from Moog Animatics. It integrates servo motor, high‑resolution encoder, power amplifier, motion controller and built‑in I/O circuits within one compact NEMA23 housing. The DE variant supports separate power supply for controller and power drive circuit. It delivers maximum 10,786 RPM high‑speed output with IP65 environmental protection rating. It executes closed‑loop position, speed and torque control directly, no external servo drive required. Widely deployed as core motion actuator for precision‑demanding industrial automation equipment.

2. Product Advantages

• ✅ All‑in‑one integrated design: motor + encoder + amplifier + controller + I/O embedded inside single unit, cuts cabinet wiring and space occupation
• ✅ High‑speed performance: max no‑load speed up to 10,786 RPM, fast dynamic response for high‑cycle‑rate equipment
• ✅ IP65 protection grade: resist dust, splash water, adapt to harsh on‑site workshop environments
• ✅ DE drive‑enable configuration: independent power supply for logic control and power stage, enhances system anti‑interference capacity
• ✅ High‑resolution built‑in optical encoder (4000 counts/rev), guarantees precise position & velocity closed‑loop feedback
• ✅ Multiple industrial communication: RS‑232, CANopen fieldbus interface, easy connection with PLC, HMI and upper‑level host system
• ✅ On‑board programmable I/O channels, supports local logic execution; free SMI programming software available for parameter tuning
• ✅ Built‑in multi‑protections: over‑current, over‑temperature, over‑voltage and stall protection for motor and drive circuit
• ✅ Compact NEMA23 standard mounting flange, convenient mechanical installation for automation machinery

3. Technical Parameters

4. Application Industries & Scenarios

Main Application Industries

• Automated production & assembly equipment
• Packaging machinery
• Robotics & small‑size manipulator
• Semiconductor manufacturing auxiliary equipment
• Medical laboratory automation devices
• Automated Guided Vehicle (AGV) motion axes
• Test & measurement instrument platforms
• CNC small‑scale processing equipment

Application Scenario Description

Mounted on mechanical transmission structures, performs high‑speed accurate positioning, speed adjustment and repeated cyclic motion. Suitable for equipment that requires compact installation space and resistance to workshop dust and water splashes.
