MOOG L180-510B-A2 Servo Drive With 2000W Power Rating Waterproof Multi Loop Control

1 pcs
MOQ
Negotiable
Price
MOOG L180-510B-A2 Servo Drive With 2000W Power Rating Waterproof Multi Loop Control
Features Gallery Product Description Chat Now
Features
Specifications
Protect Feature: Totally Enclosed,Waterproof
Application: Industrial Application
Ram: 480GB
Mountingtype: DIN Rail Or Panel Mount
Output Voltage: 0-480V
Power Rating: 2000W
Supplier Type: ODM
Package: 100% Original Package
Control Type: FVC
Panel Type: NO
Model: 00.781.2354 GTO52 BLA-CMP
Certifications: CE, RoHS
Payment: Union.Paypal TT
Type: Electrical Cabinet
Responsefrequency: 0-3000Hz
Highlight:

MOOG L180-510B-A2

,

Servo Drive 2000W

,

Servo Drive Waterproof
Basic Infomation
Brand Name: MOOG
Certification: Brand new original
Model Number: L180-510B-A2
Payment & Shipping Terms
Delivery Time: 5-7 days
Payment Terms: T/T
Supply Ability: 10000 pcs
Product Description
MOOG L180-510B-A2 Servo Drive
High-performance servo drive designed for precision industrial applications requiring dynamic response and accurate speed/torque control.
Electrical Specifications
Power Supply 230 VAC (±10% /-20%), 1-phase / 3-phase compatible
Frequency: 45–65 Hz
Control Backup: 24 VDC (20–28 VDC)
Power and Current Rated Power: 5.9 kW (6kW 3-phase full power)
Single-phase operation: Power reduced to 1/3
Continuous Current: 15 Arms
Peak Current: 21 Arms
Performance Parameters PWM Chopper Frequency: 7.5 kHz
Output Frequency: 0–500 Hz
Analog Command Input: ±10 V differential signal
Environmental Conditions Operating Temperature: 0–50℃ (derating required for 50–60℃)
Storage Temperature: -20℃ to 70℃
Core Functions
  • Multi-loop control system with torque loop and speed loop
  • Sinusoidal current output for smooth low-speed operation
  • Comprehensive protection features: short circuit, over-temperature, motor I²t thermal protection
  • Rotary transformer fault detection and monitoring
  • Programmable incremental encoder analog output (1–2048 PPR)
  • Monitoring relay output for system status
  • L180GUI software support for parameter configuration, tuning, and diagnostics
  • Firmware version A2 with enhanced debugging capabilities
Typical Applications
This servo drive is ideal for applications requiring high dynamic response and precise control:
  • Industrial robotics and automated assembly lines
  • Injection molding and packaging machinery
  • Precision positioning systems
  • High-performance motion control equipment
Commonly paired with MOOG G4xx series servo motors for complete motion control solutions.
Physical Specifications
Weight Approximately 4 kg
Cooling System Forced air cooling
Mounting Options Standard DIN rail or panel mounting
Model Code Explanation
L180 (Series) - 510 (Power Rating) - B (Hardware Version) - A2 (Firmware Version)
