Rexroth VFC3610-0K75-3P4-MNA-7P-N 0.75 kW Rated Power Frequency Inverter with Modbus Communication and 0-400 Hz Output Variable Frequency Drive

1 pcs
MOQ
Negotiable
Price
Rexroth VFC3610-0K75-3P4-MNA-7P-N 0.75 kW Rated Power Frequency Inverter with Modbus Communication and 0-400 Hz Output Variable Frequency Drive
Features Gallery Product Description Chat Now
Features
Specifications
Input Frequency: 50/60 Hz
Display Type: LCD Or LED
Acceleration/Deceleration Time: 0.1 To 6000 Seconds
Overload Capacity: 150% For 1 Minute
Output Frequency: 0-400 Hz
Protection Class: IP20 To IP54
Power Rating: 0.5 KW To 500 KW
Control Method: V/F Control, Vector Control, Sensorless Vector Control
Output Voltage: 0-480 V AC
Communication Protocols: Modbus, Profibus, Ethernet/IP
Cooling Method: Forced Air Cooling
Input Voltage: 200-480 V AC
Mounting Type: Wall-mounted Or Panel-mounted
Ambient Temperature Range: -10°C To 50°C
Harmonic Mitigation: Built-in Filters Or External Options
Highlight:

0.75 kW Rated Power Frequency Inverter

,

Modbus Communication Variable Frequency Drive

,

0-400 Hz Output VFD
Basic Infomation
Brand Name: Rexroth
Certification: Brand new original
Model Number: VFC3610-0K75-3P4-MNA-7P-N
Payment & Shipping Terms
Delivery Time: 5-7 days
Payment Terms: T/T
Supply Ability: 10000 pcs
Product Description
Rexroth VFC3610-0K75-3P4-MNA-7P-N Frequency Inverter
Electrical Specifications
Parameter Value
Rated Power 0.75 kW
Input Voltage 3*380–480 V AC, -15%/+10%
Input Frequency 50/60 Hz ±5%
Rated Output Current 4.1 A
Output Frequency Range 0–400 Hz
Overload Capacity 150% * 60 s
Starting Torque 1.5 Hz / 100%; 3 Hz / 150%
Control Method V/f Control
Cooling Method Natural Cooling (Fanless)
Protection Rating IP20
Installation Method DIN Rail Mounting, Seamless Side-by-Side Mounting
Functions and Interfaces
Standard Configuration: Modbus RTU, Built-in Braking Unit (≤22kW Model), Pluggable I/O Terminals
I/O Configuration
  • 2 Analog Inputs (0–10V / 4–20mA Switchable)
  • 1 Analog Output (0–10V / 4–20mA Switchable)
  • 5 Digital Inputs (including 1 50kHz pulse input)
  • 1 Relay Output, 1 Open Collector Output
Expansion Capabilities
2 expansion slots supporting PROFIBUS DP, CANopen and other communication modules
Debugging Features
Supports Mini USB connection to computer for quick debugging and parameter copying with software
