Home /Products/Servo Systems/HCS01.1E-W0018-A-03-E-S3-EC-NN-NN-NN-FW Rexroth Drives IndraDrive Cs Series

HCS01.1E-W0018-A-03-E-S3-EC-NN-NN-NN-FW Rexroth Drives IndraDrive Cs Series

1 pcs
MOQ
Negotiable
Price
HCS01.1E-W0018-A-03-E-S3-EC-NN-NN-NN-FW Rexroth Drives IndraDrive Cs Series
Features Gallery Product Description Chat Now
Features
Specifications
Type: Eletronic Component
Warranty: 90 Days
Inputvoltage: 200-240V AC
Protect Feature: Totally Enclosed,Waterproof
Controlmode: Position/Speed/Torque
Ac Voltage: 208-230 / 240 V,220/380V,60V,AC220V
Output Current: 0-100A
Package: 100% Original Package
Responsefrequency: Up To 2kHz
Operatingtemperature: -10°C To 50°C
Application: Industrial Control
Coolingmethod: Fan/Convection
Protection Features: Overload, Overvoltage, Overtemperature
Weight: 1.5kg
Resolution Ratio: NO
Highlight:

HCS01.1E-W0018-A-03-E-S3-EC-NN-NN-NN-FW

,

Rexroth Drives IndraDrive Cs
Basic Infomation
Brand Name: Rexroth
Certification: Brand new original
Model Number: HCS01.1E-W0018-A-03-E-S3-EC-NN-NN-NN-FW
Payment & Shipping Terms
Delivery Time: 5-7 days
Payment Terms: T/T
Supply Ability: 10000pcs
Product Description
HCS01.1E-W0018-A-03-E-S3-EC-NN-NN-NN-FW Rexroth Drives
High-performance industrial drive system designed for demanding automation applications with advanced safety features and flexible communication options.
Electrical Specifications
Parameter Specification
Main Power Supply Three-phase 200–500 V AC (±10%), 50/60 Hz
Control Power Supply 24 V DC (±20%)
Switching Frequency Up to 8 kHz
DC Bus Supports common DC bus, energy feedback
Braking Chopper Built-in, continuous braking power 0.05 kW, maximum 7.2 kW
Overload Capacity Strong overload capability for high dynamic applications
Model Code Breakdown
HCS01: IndraDrive Cs Series (Overseas version, ACS01 in China)
1E: Hardware Version
W0018: Peak Current 18 A (Continuous 7.6 A)
A: Control Unit Type (Basic)
03: Design Version
E: Power Unit Configuration (Adapted to specific power grids / Braking Requirements)
S3: Safety Function Configuration (Safe Motion S3)
EC: Multi-Ethernet Communication (PROFINET, EtherNet/IP, Modbus TCP)
NN: No Additional I/O Expansion
NN: No Higher-Level Safety Motion Module (S4/S5)
NN: No Other Special Configuration
FW: Firmware Version Identifier
Core Functions & Interfaces
Communication Interface
  • Main Communication: Multi-Ethernet (PROFINET, EtherNet/IP, Modbus TCP)
  • Optional: CANopen (configurable)
Encoder Interface
  • Hiperface / EnDat 2.1/2.2 (IndraDyn Standard)
  • BiSS, SSI, Resolver, TTL, and other protocols
Safety Functions (S3)
  • Safe Torque Off (STO): PL d / SIL 2
  • Safe Stop 1 (SS1): Safe deceleration and stop
  • Supports Safety Brake Control (SBC) with configuration
I/O and Operation
  • Standard digital I/O and analog interfaces
  • Built-in operation panel with 4 keys and digital display
  • Supports separate firmware ordering and upgrades
Environmental Specifications
Parameter Range
Operating Temperature 0°C to +40°C
Storage Temperature -25°C to +70°C
Altitude ≤ 1000 m (derating required for higher altitudes)
Installation Cabinet rail/panel mounting with forced ventilation
