Home /Products/Servo Systems/MITSUBISHI MR-J5-70A High-speed response with one-touch switching between position, speed, and torque modes

MITSUBISHI MR-J5-70A High-speed response with one-touch switching between position, speed, and torque modes

1
MOQ
Negotiable
Price
MITSUBISHI MR-J5-70A High-speed response with one-touch switching between position, speed, and torque modes
Features Gallery Product Description Chat Now
Features
Specifications
Display Size: -
Model: SSDSC2KG480G801
Protection Features: Overload, Overvoltage, Overtemperature
Input Voltage: 110-240V
Panel No: A5E02630230 A5E00213118/A5E02630231
Power Rating: 2000W
Weight: 1.5kg
Mountingtype: DIN Rail / Panel Mount
Series: D3-S4610
Resolution Ratio: NO
Payment Term: TT.Paypal.Western Union.Moneygram
Ram: 480GB
Feedbacktype: Encoder, Resolver
Coolingmethod: Fan Cooling
Port: SATA3
Highlight:

Mitsubishi MR-J5-70A servo drive

,

high-speed response servo drive

,

one-touch switching servo drive
Basic Infomation
Place of Origin: china
Brand Name: MITSUBISHI
Model Number: MR-J5-70A
Document: sv2006-5c.pdf
Payment & Shipping Terms
Packaging Details: pieces
Delivery Time: 5-8days
Payment Terms: T/T
Product Description

MR-J5

Fifth-generation MELSERVO servo system;

70:
Corresponding to rated output of 0.75kW;
A:
Compatible with single-phase / three-phase AC 200–240V, supports incremental encoder motors, and is a low-voltage general-purpose pulse type.

Core Specifications

Power Supply and Output

  • Main Circuit: Single-phase / three-phase AC 200–240V (50/60Hz), also supports DC 283–340V; Control Circuit DC 24V ± 10%
  • Rated Power 0.75kW, Rated Output Current 3.0A, 3 times overload (about 9A peak), meets short-term impact load requirements

Control Performance

  • Speed Loop Bandwidth up to 2.5kHz, significantly improves dynamic response compared to J4 series;
  • Supports seamless switching between position (pulse), speed, and torque modes;
  • 0.3-second rapid self-tuning + mechanical resonance suppression, servo ON can automatically optimize itself;
  • Pulse Command Maximum Support 4M Pulses/s; Compatible with 17-bit incremental encoders (131072 p/rev)

Safety and Diagnosis

  • Standard STO (Safety Torque Disconnection), compliant with PLd/SIL2;
  • Overcurrent / Overvoltage / Undervoltage / Overheat / Encoder Abnormality and other full protection;
  • Mechanical Diagnosis (ball screw, belt, gear), achieving predictive maintenance

Physical and Environmental

  • IP20 Protection, suitable for installation in control cabinets;
  • Operating Temperature 0 to +60℃;
  • Compact Size, facilitating dense arrangement.

Interfaces and Debugging

  • Pulse Command (open collector / differential), Analog I/O, STO Safety Terminal;
  • Through MR Configurator3 software, using USB or RS-485 to complete parameter tuning, monitoring, and alarm query;
  • Can directly interface with PLC or motion controller for pulse signals.

Compatibility and Applications

  • Recommended Motor Pairing: HG-KR73, HJ-KS703, etc. 0.75kW incremental servo motors;
  • Typical Scenarios: Small labeling / packaging machines, electronic assembly platforms, 3C equipment, precision CNC machine feed axes, laboratory automation equipment, etc.
