Honeywell HD670-T-1600-B-A04B01 Frequency Converter with 160kW Rated Power and Synchronous Motor Control featuring Modbus Communication

1 pcs
MOQ
Negotiable
Price
Honeywell HD670-T-1600-B-A04B01 Frequency Converter with 160kW Rated Power and Synchronous Motor Control featuring Modbus Communication
Features Gallery Product Description Chat Now
Features
Specifications
Humidity Range: 0-95% Non-condensing
Mounting Type: Wall-mounted Or Panel-mounted
Control Method: V/F Control, Vector Control, Sensorless Vector Control
Operating Temperature Range: -10°C To 50°C
Overload Capacity: 150% For 1 Minute
Power Rating: 0.5 KW To 500 KW
Dimensions: Varies By Model, Typically Compact Design
Input Voltage: 200-480 V AC
Output Voltage: 0-480 V AC
Display Type: LCD Or LED Display
Communication Protocols: Modbus, Profibus, Ethernet/IP
Protection Features: Overvoltage, Undervoltage, Overcurrent, Short Circuit, Overtemperature
Output Frequency: 0-400 Hz
Cooling Method: Forced Air Cooling
Efficiency: Up To 98%
Highlight:

160kW Rated Power Frequency Converter

,

Synchronous Motor Control VFD

,

Modbus Communication Variable Frequency Drive
Basic Infomation
Brand Name: Honeywell
Certification: Brand new original
Model Number: HD670-T-1600-B-A04B01
Payment & Shipping Terms
Delivery Time: 5-7 days
Payment Terms: T/T
Product Description
HD670-T-1600-B-A04B01 Honeywell Frequency Converter
High-performance general-purpose frequency converter platform designed for industrial applications requiring precise motor control and energy efficiency.
Model Configuration Analysis
Component Code Specification
Power Supply Type T Three-phase (S = Single-phase)
Rated Power 1600 160kW (400V Class)
Voltage Level B 380-480V AC (Compatible with domestic 380V power grid)
Control Version A04B01 A04 = Synchronous motor dedicated control module; B01 = Hardware/firmware version supporting synchronous + asynchronous dual-model control
Core Technical Specifications
Parameter Specification
Control Method Synchronous motor open-loop/closed-loop, asynchronous motor open-loop/closed-loop; Asynchronous 0.25Hz up to 200% rated torque, synchronous 1.5% rated speed up to 150% torque
Speed Range Open-loop 1:200; Closed-loop 1:5000; Speed stability open-loop ±0.5%, closed-loop ±0.02%
Rated Data 160kW/400V; Rated current: approx. 290-310A; Suitable motor power: ≤160kW
Frequency Specifications Maximum frequency: 600Hz; Torque accuracy: ±5% (open loop)/±3% (closed loop); Torque response time: 20ms (open loop)/10ms (closed loop)
Communication & Frequency Setting Standard Modbus RTU (RS485, up to 500m); Supports keyboard, terminal analog signals, multi-speed, simple PLC, PID, and other frequency setting methods
Protection Functions Full protection against overcurrent, overvoltage, undervoltage, overheating, short circuit, motor PTC, communication abnormalities, and grounding faults
Structure & Heat Dissipation Independent air duct, supports external radiator cabinet installation; requires external braking unit and braking resistor
Environmental Conditions Operating temperature: -10~40℃ (40-50℃ derating); Humidity: 5-95% non-condensing; Altitude: 0-2000m
Key Functions and Configuration
Ideal Applications: Energy-saving retrofitting of high-power fans and pumps, large compressors, mining machinery, hoisting equipment, metallurgical rolling mills, and dedicated production lines for synchronous motors. Particularly suitable for factories with mixed synchronous and asynchronous lines.
  • Closed-Loop Expansion: For encoder closed-loop control, use HD670-PG series feedback card
  • Installation Specifications: Vertical installation with proper ventilation; for long cables (>100m), add output reactor to reduce dv/dt impact on motor insulation
  • External Equipment Selection: Circuit breaker ≥400A, contactor ≥350A, incoming line reactor (recommended for unstable power grids), external braking unit + braking resistor (essential for frequent braking scenarios)
