Honeywell SmartLine STD800 Differential Pressure Transmitter with ±0.025% Accuracy 400:1 Range Ratio and Advanced Diagnostics

1 pcs
MOQ
Negotiable
Price
Honeywell SmartLine STD800 Differential Pressure Transmitter with ±0.025% Accuracy 400:1 Range Ratio and Advanced Diagnostics
Features Gallery Product Description Chat Now
Features
Specifications
Highlight:

±0.025% Accuracy Pressure Transmitter

,

400:1 Range Ratio Differential Pressure Transmitter

,

Advanced Diagnostics SmartLine Transmitter
Basic Infomation
Brand Name: Honeywell
Certification: Brand new original
Model Number: HD670-T-0185-B-A04B01
Payment & Shipping Terms
Delivery Time: 5-7 days
Payment Terms: T/T
Supply Ability: 10000 pcs
Product Description
Honeywell SmartLine® STD800 Differential Pressure Transmitter
The Honeywell SmartLine® STD800 is a high-performance differential pressure transmitter designed for precise measurement of gases, liquids, and vapors. Part of the ST800 pressure family, this instrument excels in flow rate measurement (via orifice plate/venturi), level monitoring (closed/open tanks), and filter differential pressure applications across demanding industrial environments.
Core Applications & Industries
This differential pressure transmitter serves critical measurement functions in petrochemical, power generation, metallurgy, paper manufacturing, pharmaceutical, and water treatment industries.
Technical Specifications
Measurement Performance
  • Accuracy: Maximum ±0.025% of Range (URL)
  • Range Ratio: Up to 400:1 (STD820/830/870 models)
  • Long-Term Stability: ±0.01% URL/year with 15-year warranty
  • Response Time: 90ms (typical)
  • Static Pressure Influence: Automatic compensation reduces high-pressure errors
  • Overpressure Protection: Up to 210 bar protection against shock damage
Measuring Range by Model
Model Differential Pressure Range Range Ratio Accuracy
STD810 -10inH₂O ~ +10inH₂O (-25mbar ~ +25mbar) 100:1 0.015%
STD815 -100inH₂O ~ +100inH₂O (-250mbar ~ +250mbar) 200:1 0.020%
STD820/825/830/870 0.1bar ~ 210bar 400:1 0.025%
Note: Units can be switched between inH₂O, mbar, kPa, psi, bar, etc.
Electrical & Communication
  • Power Supply: 24VDC two-wire with reverse polarity protection
  • Output: 4–20mA HART (standard); optional Foundation Fieldbus, WirelessHART
  • Display: Multi-window LCD (optional) with field button configuration
  • NAMUR NE43: Fault Mode ≤3.6mA (low) or ≥21.0mA (high)
Environmental & Installation
  • Operating Temperature: -40°C ~ +85°C (electronics); -40°C ~ +121°C (process connection)
  • Protection Rating: IP66/IP67 with explosion-proof certifications (ATEX/IECEx/CSA)
  • Process Connection: 1/2" NPT internal thread, flange, direct mounting, remote sealing options
  • Structure: Modular design allowing on-site component replacement without affecting certification
Key Features & Advantages
  • Advanced Diagnostics: Built-in pressure line blockage detection, sensor health monitoring, and process anomaly warnings
  • Multiple Calibration Options: Supports 1/2/3 sets of factory calibrations with one-click on-site range switching
  • Safety & Compliance: SIL 2/3 functional safety certification with dual sealing and ANSI/NFPA/ISA standards compliance
  • System Integration: Deep compatibility with Honeywell Experion PKS for plug-and-play operation
  • Extreme Conditions: Wide temperature range operation with remote sealing options for corrosive media isolation
