Siemens 6SL3244-0BB13-1BA1 SINAMICS G120 CU240E-2 F Control Unit E-type with Safety Integrated F-type functions

1pcs
MOQ
Negotiable
Price
Siemens 6SL3244-0BB13-1BA1 SINAMICS G120 CU240E-2 F Control Unit E-type with Safety Integrated F-type functions
Features Gallery Product Description Chat Now
Features
Specifications
Mounting Type: Wall-mounted Or Panel-mounted
Ambient Temperature Range: -10°C To 50°C
Soft Stop Time: 0.1 To 60 Seconds
Humidity: 0 To 95% Non-condensing
Input Voltage: 200-480V AC
Communication Protocols: Modbus, Profibus, Ethernet/IP
Control Method: V/f Control, Vector Control, Sensorless Vector Control
Overload Capacity: 150% Rated Current For 60 Seconds
Power Range: 0.5 KW To 500 KW
Cooling Method: Forced Air Cooling
Protection Features: Overcurrent, Overvoltage, Undervoltage, Phase Loss, Thermal Overload
Soft Start Time: 0.1 To 60 Seconds
Starting Torque: Up To 150% Of Rated Torque
Frequency Range: 0-400 Hz
Output Voltage: 0-480V AC
Highlight:

Siemens SINAMICS G120 control unit

,

VFD CU240E-2 F-type

,

SINAMICS G120 Safety Integrated
Basic Infomation
Place of Origin: Germany
Brand Name: Siemens
Model Number: 6SL3244-0BB13-1BA1
Document: 6SL3244-0BB13-1BA1_datashee...en.pdf
Payment & Shipping Terms
Delivery Time: 5-7work day
Payment Terms: T/T
Supply Ability: 10pcs 1week
Product Description
Siemens 6SL3244-0BB13-1BA1 SINAMICS G120 CU240E-2 F Control Unit
E-type Control Unit with Safety Integrated F-type functions for SINAMICS G120 Standard Inverters
Product Specifications
Parameter Value
Manufacturer Siemens
Product Line SINAMICS G120
Product Type Control Unit CU240E-2 F E-type
Order Number (MLFB) 6SL3244-0BB13-1BA1
Supply Voltage 24 V DC
Current Consumption 0.5 A
Power Loss 5.5 W
Communication Interface RS 485 (supports USS/Modbus RTU)
Digital Inputs (DI) 6
Digital Outputs (DQ) 3
Analog Inputs (AI) 2 (Differential input)
Analog Outputs (AQ) 2 (Non-isolated)
Fail-Safe Digital Inputs (F-DI) Max. 3
Degree of Protection (IP Rating) IP20
Ambient Temperature Range 0 to +50 °C (without Power Module and Panel)
Mounting Type DIN rail
Weight 0.19 kg
Power Range Compatibility 0.37 to 250 kW SINAMICS G120 Standard Inverter
Safety Certification SIL2 PLd Cat 3
RoHS Compliance Yes
Safety Functions
  • STO (Safe Torque Off)
  • SS1 (Safe Stop 1)
  • SLS (Safety Limited Speed)
  • SSM (Safe Speed Monitor)
  • SDI (Safe Direction)
Additional Interfaces
  • PTC/KTY interface
  • USB interface
  • SD/MMC card slot
