Siemens 6SL3210-1PE32-5UL0 PM240-2 Power Module SINAMICS G120 POWER MODULE PM240-2 WITHOUT FILTER WITH BUILT IN BRAKING CHOPPER

1pcs
MOQ
Negotiable
Price
Siemens 6SL3210-1PE32-5UL0 PM240-2 Power Module SINAMICS G120 POWER MODULE PM240-2 WITHOUT FILTER WITH BUILT IN BRAKING CHOPPER
Features Gallery Product Description Chat Now
Features
Specifications
Model: FX5U-32MT/ES
Operatingtemperature: -20°C To 60°C
Weight: 0.15 KG
Expandability: Modular With Expansion Modules
Actual Price: Based On Offer
Applications: Manufacturing Automation, Process Control, Robotics, Assembly Lines
Output Points: 20
Productname: Programmable Logic Controller (PLC)
Mountingtype: DIN Rail Or Panel Mount
Programminglanguage: Ladder Logic, Function Block Diagram, Structured Text, Instruction List, Sequential Function Chart
Supply Voltage Type: AC
Condition: New Original With Sealed
Part No: E-01D
Power Supply Voltage: 100 – 240VAC.
Total Points: 60 Points.
Highlight:

Siemens PM240-2 Power Module

,

SINAMICS G120 VFD drive

,

PM240-2 without filter with braking chopper
Basic Infomation
Place of Origin: Germany
Brand Name: Siemens
Model Number: 6SL3210-1PE32-5UL0
Document: 6SL3210-1PE32-5UL0_datashee...en.pdf
Payment & Shipping Terms
Delivery Time: 5-7work day
Payment Terms: T/T
Supply Ability: 10pcs 1week
Product Description
Siemens 6SL3210-1PE32-5UL0 PM240-2 Power Module
SINAMICS G120 POWER MODULE PM240-2 WITHOUT FILTER WITH BUILT IN BRAKING CHOPPER
Product Specifications
Parameter Name Parameter Value
Manufacturer Siemens
Product Line SINAMICS G120
Module Type PM240-2 Power Module
Part Number 6SL3210-1PE32-5UL0
Input Voltage 3AC 380-480V ±10% / +10/-20%
Input Frequency 47-63 Hz
Input Phases Three-phase AC
Low Overload Power Rating 132 kW / 200 hp
High Overload Power Rating 110 kW / 150 hp
Low Overload Output Current 250 A
High Overload Output Current 205 A
Peak Output Current 410 A
Output Voltage 400 V (IEC) / 480 V (NEC)
Output Frequency Range 0-550 Hz
Pulse Switching Frequency 2 kHz
Low Overload Ambient Temperature -20 to +40 °C
High Overload Ambient Temperature -20 to +50 °C
Protection Rating IP20 / UL open
Cooling Method Air-cooled internally
Max Motor Cable Distance 300 m (shielded), 450 m (unshielded)
Energy Efficiency 98%
Power Factor 0.95
Offset Factor cos φ 0.99
Sound Pressure Level (1m) 72 dB
Approved CU Firmware Version V4.7 HF8
Key Features
Built-in braking chopper for dynamic braking applications
High efficiency rating of 98% for energy savings
Wide operating temperature range for industrial environments
Compatible with SINAMICS G120 control units
Robust overload capabilities for demanding applications
Physical Specifications
Dimensions: 708 x 305 x 357 mm (HxWxD)
Net Weight: 62 kg
Shipping Weight: 4.99 kg
Packaging Dimensions: 469 x 745 x 385 mm
Certifications & Compliance
UL, CUL, CE, C-Tick, SEMI F47
EAN: 4042948668153
UPC: 804766236907
