Siemens 6SL3210-1PE11-8UL1 SINAMICS Power Module PM240-2 unfiltered with integrated braking chopper

1pcs
MOQ
Negotiable
Price
Siemens 6SL3210-1PE11-8UL1 SINAMICS Power Module PM240-2 unfiltered with integrated braking chopper
Features Gallery Product Description Chat Now
Features
Specifications
Dimensions: 90 X 70 X 75 Mm
Part No: D0-06DR
Output Points: 24 Points.
Actual Price: Negotiabled
Output Typt: Relay
Power Supply Voltage: 100 – 240VAC.
CPU_Speed: 100 MHz
Input Points: 36 Points.
Points: 40 (24DI+16DO)
Mounting_Type: DIN Rail
Number_of_I/O_Points: 128
Manufacturer: Siemens
Weight: 300 G
Supply Voltage Type: AC
Power_Supply: 24 V DC
Highlight:

Siemens SINAMICS Power Module PM240-2

,

VFD with integrated braking chopper

,

unfiltered variable frequency drive
Basic Infomation
Place of Origin: Germany
Brand Name: Siemens
Model Number: 6SL3210-1PE11-8UL1
Document: 6SL3210-1PE11-8UL1.pdf
Payment & Shipping Terms
Delivery Time: 5-7work day
Payment Terms: T/T
Supply Ability: 20PCS 1WEEK
Product Description
Siemens 6SL3210-1PE11-8UL1 SINAMICS Power Module PM240-2
Unfiltered power module with integrated braking chopper for industrial drive applications.
Product Overview
The SINAMICS G120 Power Module PM240-2 provides reliable motor control with integrated braking chopper functionality, designed for demanding industrial environments.
Technical Specifications
Parameter Value
Model Number 6SL3210-1PE11-8UL1
Product Description SINAMICS Power Module PM240-2 unfiltered with integrated braking chopper
Series SINAMICS G120
Input Voltage 380-480 V AC +10/-10%
Input Phase Number 3
Input Frequency 47-63 Hz
Input Current (Low Overload - LO) 2.3 A
Input Current (High Overload - HO) 2 A
Output Voltage 0-480 V AC (depending on input voltage)
Output Phase Number 3
Output Frequency 0-600 Hz
Output Current (LO) 2.6 A
Output Current (HO) 1.7 A
Rated Power (LO) 0.55 kW (0.75 HP)
Rated Power (HO) 0.37 kW (0.5 HP)
Overload Capability (LO) 150% for 3 s, 110% for 57 s, 100% for 240 s
Overload Capability (HO) 200% for 3 s, 150% for 57 s, 100% for 240 s
Degree of Protection IP20 / UL open type
Braking Chopper Integrated
Filter Class Unfiltered
Performance Characteristics
Parameter Value
Efficiency (η) 0.96
Power Factor (λ) 0.85
Offset Factor (cos φ) 0.95
Sound Pressure Level (1m) 72 dB
Power Loss 0.04 kW
Cooling Air Requirement 5 l/s
Cooling Method Forced air cooling (push-through technology)
Environmental Specifications
Parameter Value
Ambient Temperature (Operation LO) -10 to +40 °C
Ambient Temperature (Operation HO) -10 to +50 °C
Ambient Temperature (Storage/Transport) -25 to +70 °C
Relative Humidity 5-95% (non-condensing)
Installation Altitude Up to 1000 m (derating above 1000 m)
Physical Dimensions
Frame Size: A
Dimensions (H x W x D): 90 x 185 x 280 mm
Net Weight: 1.3 kg
Gross Weight (incl. package): 1.598 kg
Product Identification & Compliance
EAN/GTIN: 4042948665916
WEEE Number: DE 23691322
RoHS Compliance: Conforms
