Allen-Bradley 700-FSM6UU23-EX 700-FS High Performance Timing Relay (Hazardous Location

2pcs
MOQ
Negotiable
Price
Allen-Bradley 700-FSM6UU23-EX 700-FS High Performance Timing Relay (Hazardous Location
Features Gallery Product Description Chat Now
Features
Specifications
Actual Price: Based On Offer
CPU_Speed: 100 MHz
Number_of_Outputs: 10
Manufacturer: Siemens
Output Method: Transistor
Weight: 0.5 Kg
Application: Spinning Machine, Conveyer Belt
Model: S7-1200
Point: 14 (8DI+6DO)
Supply Voltage Type: AC
Input Points: 36DI
Output Typt: Relay
Power Supply Voltage: AC240-360V.
Points: 40 (24DI+16DO)
Output Points: 20
Highlight:

Allen-Bradley hazardous location timing relay

,

700-FSM6UU23-EX high performance relay

,

VFD compatible timing relay
Basic Infomation
Place of Origin: USA
Brand Name: Allen-Bradley
Model Number: 700-FSM6UU23-EX
Document: 700-FSM6UU23-EX.pdf
Payment & Shipping Terms
Delivery Time: 5-7work day
Payment Terms: T/T
Supply Ability: 50PCS 1week
Product Description
Allen-Bradley 700-FSM6UU23-EX High Performance Timing Relay
Hazardous location certified multi-function timing relay designed for industrial automation applications requiring precise timing control in challenging environments.
Product Overview
Model Number700-FSM6UU23-EX
Product Series700-FS
Product TypeMulti-function Timing Relay
ManufacturerAllen-Bradley / Rockwell Automation
Lifecycle StatusActive
Key Specifications
Input Voltage24-48V DC / 24-240V AC, 50/60 Hz
Voltage ToleranceDC: -20% to +20%, AC: -15% to +10%
Current Consumption1 mA
Contact Rating5 A at 120 VAC
Contact ConfigurationSPDT (1 C/O - Single Pole Double Throw)
Timing Capabilities
Timing Range: 0.05 s to 100 h
Ten Selectable Time Ranges:
  • 0.05-1 s
  • 0.15-3 s
  • 0.5-10 s
  • 1.5-30 s
  • 0.15-3 min
  • 0.5-10 min
  • 1.5-30 min
  • 0.5-1 h
  • 15-300 min
  • 0.5-10 h
Timing Functions (10 options):
  • A: On-delay
  • A+: On-delay with reset
  • B: Off-delay
  • C: On-and-off-delay
  • T: One Shot with B1
  • D: Fleeting Off-delay
  • E: Flasher (Pulse)
  • FG: Flasher (Pause)
  • L: On-delay Pulse Generator
  • Y1: Pulse Converter
Environmental & Physical Specifications
Operating Temperature-20°C to 60°C (-4°F to 140°F)
Storage Temperature-40°C to 70°C (-40°F to 158°F)
Relative Humidity25-85% (non-condensing)
Frame Size22.5 mm wide
Dimensions (W×H×D)22.5 mm × 70 mm × 60 mm (0.89×2.76×2.36 in)
WeightApproximately 0.15 kg (0.33 lbs)
Enclosure RatingIP20 (Terminal: IP20 per IEC 947-1)
Mounting Options35 mm DIN Rail (without socket)
Hazardous Location Certifications
ATEX: II 3 G, EEx nL IIC T4, DEMKO 04 ATEX 0404974X
IEC Ex: II 3 G, EEx nL IIC T4
UL Listed: Class 1, Div. 2, Groups A,B,C,D
CSA: Class 1, Zone 2, Group IIC
Other Certifications: CE, CCC, RCM (Australia)
Special Installation Requirements
  • Must be installed in an ATEX Certified IP54 enclosure
  • Accessible only by use of a tool
Typical Applications
  • Hazardous industrial environments
  • General industrial automation
  • Machinery control requiring timing functions
  • Process control systems
  • Pump and motor control with delayed start/stop
  • Conveyor systems
  • Lighting control with timing sequences
