Siemens 6SL3040-1MA00-0AA0 SINAMICS S120 Control Unit CU320-2 DP (Without Compact Flash Card)

1
MOQ
Negotiable
Price
Siemens 6SL3040-1MA00-0AA0 SINAMICS S120 Control Unit CU320-2 DP (Without Compact Flash Card)
Features Gallery Product Description Chat Now
Features
Specifications
Memory: 50 KB
Part Type: Sysmac CPM2A
Dimensions: 90 Mm X 100 Mm X 75 Mm
Manufacturer: Siemens
Color: Normal
Weight: 0.5 Kg
Mpu Points: 12 (8DI + 4DO)
Output Typt: Relay
Number_of_Outputs: 10
Mounting_Type: DIN Rail
Operating_Temperature_Range: -20°C To 60°C
CPU_Speed: 100 MHz
Part No: E-05B-EX1
Points: 40 (24DI+16DO)
Output Points: 16DO
Highlight:

Siemens SINAMICS S120 Control Unit

,

CU320-2 DP VFD without flash card

,

SINAMICS S120 variable frequency drive
Basic Infomation
Place of Origin: Germany
Brand Name: Siemens
Model Number: 6SL3040-1MA00-0AA0
Document: 6SL3040-1MA00-0AA0_datashee...en.pdf
Payment & Shipping Terms
Delivery Time: 5-7work day
Payment Terms: T/T
Supply Ability: 10pcs 1week
Product Description
Siemens 6SL3040-1MA00-0AA0 SINAMICS S120 Control Unit CU320-2 DP
The SINAMICS S120 Control Unit CU320-2 DP is a high-performance industrial automation controller designed for sophisticated motion control applications. This model operates without a Compact Flash Card and provides comprehensive control capabilities for multi-axis systems.
Technical Specifications
Parameter Value
Model Number 6SL3040-1MA00-0AA0
Product Series SINAMICS S120
Product Type Industrial Automation Control Unit
Digital Inputs 12 channels
Input Voltage Range -3 V to +30 V DC
Digital I/O 8 bidirectional channels
Power Supply 24 V DC (20.4-28.8 V range)
Max Power Consumption 1.0 A (without digital outputs)
Communication Interfaces PROFIBUS DP (1 port), DRIVE-CLiQ (4 ports), RS232 (1 port), Ethernet (1 port)
Dimensions (W×H×D) 50 mm × 300 mm × 226 mm (1.97×11.81×8.90 in)
Weight 2.20 kg (4.85 lb)
Operating Temperature 0°C to 55°C (32°F to 131°F)
Input/Output Characteristics
Digital Inputs: 12 channels with -3 V to +30 V DC range
Low Level Input: -3 V to +5 V DC
High Level Input: +15 V to +30 V DC
Input Current (24V DC): 3.5 mA (typical)
Digital I/O: 8 bidirectional channels with 500 mA max per channel
I/O Output Voltage: 24 V DC (as output)
Short-Circuit Protection: Yes (continuous)
Environmental Specifications
  • Mounting: DIN rail or cabinet mounting plate
  • Installation Altitude: 2,000 m max (6,561 ft)
  • Operating Temperature: 0°C to 55°C (32°F to 131°F)
  • Storage Temperature: -25°C to 55°C (-13°F to 131°F)
  • Transport Temperature: -40°C to 70°C (-40°F to 158°F)
  • Relative Humidity: 95% max (at 40°C)
Cable Specifications
  • Power Supply: 2.5 mm² (AWG 14) max
  • Digital I/O: 1.5 mm² (AWG 16) max
Standards & Compliance
CE, KC, cULus, EAC, C-Tick (RCM)
Typical Applications
CNC machines, robotics, packaging machinery, multi-axis control systems
