Pepperl+Fuchs KFU8-UFC-Ex1.D Frequency Converter Isolated Barrier with Alarm

1 pcs
MOQ
Negotiable
Price
Pepperl+Fuchs KFU8-UFC-Ex1.D Frequency Converter Isolated Barrier with Alarm
Features Gallery Product Description Chat Now
Features
Specifications
Weight: Approx. 0.5 To 1.5 Kg
Powersupply: 24V DC / 110V AC / 220V AC
Dimensions: Varies By Model
Material: Industrial Grade Plastic And Metal
Outputvoltage: 24V DC
Warrantyperiod: 1 To 3 Years
Communicationprotocol: Modbus, Ethernet/IP, Profibus
Numberofoutputs: 16 Digital Outputs
Safetystandardscompliance: IEC 61508, ISO 13849
Actual Value: Negotiabled Price
Point: 14 (8DI+6DO)
Userinterface: HMI Touchscreen / Remote Monitoring
Installationtype: Panel Mounted, Rack Mounted
Outputtype: Digital And Analog Outputs
Model: S7-1200
Highlight:

Pepperl+Fuchs frequency converter isolated barrier

,

KFU8-UFC-Ex1.D frequency converter with alarm

,

isolated barrier for protection and control
Basic Infomation
Brand Name: PEPPERL+FUCHS
Model Number: KFU8-UFC-Ex1.D
Payment & Shipping Terms
Delivery Time: 5-7 days
Payment Terms: T/T
Supply Ability: 1000 pcs
Product Description
I. Core Basic Information
Brand / Model: Pepperl+Fuchs KFU8-UFC-Ex1.D
Product Category: Isolated Safety Barrier / Frequency Signal Converter (with Alarm)
Number of Channels: 1 Channel
Power Supply: Wide-range AC/DC universal (Terminals 23/24)
Mounting: 35 mm DIN rail
Product Status: In production, regular supply
Core Functions:
  • Receives frequency/pulse signals from NAMUR sensors/dry contacts (1 mHz–5 kHz)
  • Isolates and converts to 0/4–20 mA analog output
  • Built-in 2 relays + 1 transistor switch alarm (over-limit/fault)
  • Supports SIL 2 functional safety and line fault detection (LFD)
II. Key Technical Parameters
1. Power Supply Parameters
ParameterValue
Supply Voltage20–90 V DC / 48–253 V AC (50/60 Hz)
Power Consumption≤ 2 W (DC) / 2.2 W (AC)
Power Loss≤ 2.5 VA (DC) / 3 VA (AC)
2. Field Side (Hazardous Area, Input I)
ParameterValue
Input TypeNAMUR Sensor (EN 60947-5-6) / Dry Contact
Input Frequency0.001 Hz–5 kHz
Pulse Width> 50 µs
Intrinsically Safe ParametersOpen Circuit Voltage 18 V / Short Circuit Current 5 mA
Line Fault DetectionOpen Circuit ≤0.15 mA / Short Circuit >6.5 mA
Terminals1+, 3- (Intrinsically Safe)
3. Control Side (Safe Area, Output)
Output TypeSpecificationTerminals
Analog (IV)0/4–20 mA, Load 0–600 Ω7-, 8+
Relay I250 V AC/2 A; 40 V DC/2 A10, 11, 12
Relay IISame as Relay I16, 17, 18
Transistor (III)40 V DC, 50 mA (short circuit protection)19+, 20-
4. Mechanical and Environmental
ParameterValue
Operating Temperature-20°C to +60°C
Isolation VoltageInput / Output / Power Supply 500 V DC
Safety CertificationsATEX, IECEx, SIL 2 (IEC 61508)
Configuration Method: Panel Buttons / PACTware Software
III. Functions and Features
  • Frequency to Analog: Linearly converts speed/flow/pulse signals to 4–20 mA for easy integration with PLC/DCS.
  • Multi-channel Alarm: 2 relays + 1 transistor, with configurable upper and lower limits, window, fault, and other alarm logic.
  • Line Diagnostics: Automatically detects sensor open circuits/short circuits; LED alarm and output trigger in case of fault.
  • Startup Shielding: Configurable 1–1000 s startup delay to avoid false alarms upon startup.
  • Wide temperature and voltage range: adaptable to harsh working conditions and various power supply scenarios.
IV. Typical Application Scenarios
  • Speed/speed/flow/counting monitoring in hazardous areas (e.g., conveyors, pumps, fans).
  • Pulse signal isolation and alarm in explosion-proof environments such as chemical, petroleum, and pharmaceutical industries.
  • Overspeed/underspeed/locked rotor protection and interlocking control for equipment.
