Home /Products/Valve Positioners/Siemens Valve Positioner 6DR5010-0EN00-0AA0 24V DC (19.2~30V DC) 4~20mA / 0~10V DC 4~20mA 0.4~0.7 MPa

Siemens Valve Positioner 6DR5010-0EN00-0AA0 24V DC (19.2~30V DC) 4~20mA / 0~10V DC 4~20mA 0.4~0.7 MPa

1pcs
MOQ
Negotiable
Price
Siemens Valve Positioner 6DR5010-0EN00-0AA0 24V DC (19.2~30V DC) 4~20mA / 0~10V DC 4~20mA 0.4~0.7 MPa
Features Gallery Product Description Chat Now
Features
Specifications
Mounting: Direct Mount / Remote Mount
Protection Class: IP65 / IP67
Accuracy: ±1% Of Full Scale
Communication Protocol: HART / Foundation Fieldbus / Profibus
Response Time: Less Than 1 Second
Type: Electro-pneumatic / Pneumatic / Digital
Input Signal: 4-20 MA / 0-10 V / HART / Fieldbus
Output Signal: 3-15 Psi / 0.2-1.0 Bar Pneumatic Signal
Power Supply: 24 V DC / 110 V AC / 220 V AC
Material: Aluminum Alloy / Stainless Steel
Function: Control Valve Actuator Position Based On Control Signal
Applications: Process Control In Chemical, Oil & Gas, Power Plants
Operating Temperature: -40°C To +85°C
Feedback: Integrated Position Feedback Sensor
Highlight:

Siemens valve positioner 24V DC

,

valve positioner 4~20mA signal

,

industrial valve positioner 0.4~0.7 MPa
Basic Infomation
Place of Origin: China
Brand Name: Siemens
Model Number: 6DR5010-0EN00-0AA0
Document: A700000008510566.pdf
Payment & Shipping Terms
Delivery Time: 1week
Payment Terms: T/T
Supply Ability: 20PCS 1WEEK
Product Description
Siemens Valve Positioner 6DR5010-0EN00-0AA0
Key Specifications: 24V DC (19.2~30V DC) | 4~20mA / 0~10V DC Input | 4~20mA Output | 0.4~0.7 MPa Air Supply | Explosion Proof Single-Acting Design
Product Overview
Siemens SIPART PS2 valve positioners provide precise control and reliable operation for industrial valve applications. The 6DR5010-0EN00-0AA0 model features explosion-proof certification and single-acting operation suitable for hazardous environments.
Complete Product Series Specifications
Product Series Part Number Model Name Supply Voltage Input Signal Output Signal Air Supply Pressure Max Working Pressure Protection Class Ambient Temperature Key Features
Siemens Valve Positioner 6DR5010-0NG00-0AA0 6DR5010 24V DC (19.2~30V DC) 4~20mA / 0~10V DC 4~20mA 0.4~0.7 MPa 1.0 MPa IP65/IP66/IP67 -40°C~+70°C Basic Type; Single-Acting; Non-Explosion Proof; 2-wire/4-wire Optional
Siemens Valve Positioner 6DR5010-0NN00-0AA0 6DR5010 24V DC (19.2~30V DC) 4~20mA / 0~10V DC 4~20mA 0.4~0.7 MPa 1.0 MPa IP65/IP66/IP67 -40°C~+70°C Basic Type; Double-Acting; Non-Explosion Proof; 2-wire/4-wire Optional
Siemens Valve Positioner 6DR5010-0EN00-0AA0 6DR5010 24V DC (19.2~30V DC) 4~20mA / 0~10V DC 4~20mA 0.4~0.7 MPa 1.0 MPa IP65/IP66/IP67 Ex ia IIC T6 Ga / -40°C~+70°C Explosion Proof; Single-Acting; Ex Certified; 2-wire System
Siemens Valve Positioner 6DR5020-0NG00-0AA0 6DR5020 24V DC (19.2~30V DC) 4~20mA / Bus (PROFIBUS PA) 4~20mA / Bus Feedback 0.4~0.7 MPa 1.0 MPa IP65/IP66/IP67 -40°C~+70°C Bus Type; Single-Acting; PROFIBUS PA; Non-Explosion Proof
Siemens Valve Positioner 6DR5020-0NN00-0AA0 6DR5020 24V DC (19.2~30V DC) 4~20mA / Bus (PROFIBUS PA) 4~20mA / Bus Feedback 0.4~0.7 MPa 1.0 MPa IP65/IP66/IP67 -40°C~+70°C Bus Type; Double-Acting; PROFIBUS PA; Non-Explosion Proof
Siemens Valve Positioner 6DR5020-0EN00-0AA0 6DR5020 24V DC (19.2~30V DC) 4~20mA / Bus (PROFIBUS PA) 4~20mA / Bus Feedback 0.4~0.7 MPa 1.0 MPa IP65/IP66/IP67 Ex ia IIC T6 Ga / -40°C~+70°C Bus Type; Single-Acting; PROFIBUS PA; Ex Certified
Siemens Valve Positioner 6DR5310-0NG00-0AA0 6DR5310 24V DC (19.2~30V DC) 4~20mA / 0~10V DC 4~20mA 0.3~0.7 MPa 1.6 MPa IP65/IP66/IP67 -40°C~+80°C High Performance; Single-Acting; High Precision; Non-Explosion Proof
Siemens Valve Positioner 6DR5310-0NN00-0AA0 6DR5310 24V DC (19.2~30V DC) 4~20mA / 0~10V DC 4~20mA 0.3~0.7 MPa 1.6 MPa IP65/IP66/IP67 -40°C~+80°C High Performance; Double-Acting; High Precision; Non-Explosion Proof
Siemens Valve Positioner 6DR5310-0EN00-0AA0 6DR5310 24V DC (19.2~30V DC) 4~20mA / 0~10V DC 4~20mA 0.3~0.7 MPa 1.6 MPa IP65/IP66/IP67 Ex ia IIC T6 Ga / -40°C~+80°C High Performance; Single-Acting; Ex Certified; High Precision
Siemens Valve Positioner 6DR5320-0NG00-0AA0 6DR5320 24V DC (19.2~30V DC) 4~20mA / Bus (PROFIBUS PA/FOUNDATION Fieldbus) 4~20mA / Bus Feedback 0.3~0.7 MPa 1.6 MPa IP65/IP66/IP67 -40°C~+80°C High Performance Bus Type; Single-Acting; Multi-Bus; Non-Explosion Proof
Siemens Valve Positioner 6DR5320-0NN00-0AA0 6DR5320 24V DC (19.2~30V DC) 4~20mA / Bus (PROFIBUS PA/FOUNDATION Fieldbus) 4~20mA / Bus Feedback 0.3~0.7 MPa 1.6 MPa IP65/IP66/IP67 -40°C~+80°C High Performance Bus Type; Double-Acting; Multi-Bus; Non-Explosion Proof
Siemens Valve Positioner 6DR5320-0EN00-0AA0 6DR5320 24V DC (19.2~30V DC) 4~20mA / Bus (PROFIBUS PA/FOUNDATION Fieldbus) 4~20mA / Bus Feedback 0.3~0.7 MPa 1.6 MPa IP65/IP66/IP67 Ex ia IIC T6 Ga / -40°C~+80°C High Performance Bus Type; Single-Acting; Multi-Bus; Ex Certified
Application Features
Siemens valve positioners offer reliable performance across various industrial applications including process automation, chemical processing, oil and gas, and power generation. The comprehensive product line provides solutions for standard, bus communication, and high-performance requirements with options for hazardous area certification.
Tag:

Electro Pneumatic Valve Positioner

Combustion Valve

Electro Hydraulic Servo Valve
