M12-D4-KP-K D-Coding 4 Pin Female Right Angle M12 Circular Connectors PCB Receptacle

1 pcs
MOQ
M12-D4-KP-K D-Coding 4 Pin Female Right Angle M12 Circular Connectors PCB Receptacle
Features Gallery Product Description Chat Now
Features
Specifications
Control Mode: V/F Control
Max Switching Current: 6 A
Networkinterface: 10/100/1000 Mbps Ethernet Ports
Highlight:

D-Coding 4 Pin M12 Circular Connector

,

Latch Lock M12 Circular Connector

,

PCB Mount M12 Circular Connector
Basic Infomation
Model Number: M12-D4-KP-K
Payment & Shipping Terms
Delivery Time: 1week
Payment Terms: T/T
Supply Ability: 10000 pcs
Product Description

M12 Circular Connector Waterproof Overmolded Cable Assembly M12-D4-KP-K

M12 Circular Connector Waterproof Overmolded Cable Assembly M12-D4-KP-K

Key Features

  • Standard M12 threaded coupling mechanism, compliant with IEC 61076-2-101
  • Available in unshielded versions, high-strength all-plastic or metal housing, lightweight and durable
  • High-grade flame-retardant PA66 Insulator material, rated UL 94 V-0
  • Heavy gold plating on contact surfaces, ensures low Contact resistance (≤3mΩ) and extended mating life

Product Overview

The M12 circular sealed connector uses D-coding for mating-error prevention. This configuration is a female right-angle male connector with latch, providing excellent mechanical stability and electrical continuity for durable, reliable connections in harsh industrial environments.

Key Technical specifications

Parameter Value
Contact Gender female
Wiring Method PCB pins
Mounting Method panel/PCB mounting
Shielded unshielded
Rated voltage 250V
Rated current 4A
Degree of protection IP67, when mated
Operating temperature Connector: -45℃ ~ +115℃
Contact resistance ≤ 3 mΩ
Insulation resistance ≥ 100 MΩ
Mechanical endurance ≥ 500 mating cycles
Rated impulse voltage 500V / 800V / 1500V / 2500V
Shell material nickel-plated brass / nickel-plated zinc alloy
Insulator material PA66 (UL 94-V0)
Contact material gold-plated brass

Dimensional drawing

Product Part-number designation Breakdown

  1. M12 Product type: M12 circular connector
  2. D4 D Coding / 4 contacts (Number of contacts)
  3. KP-K right-angle male connector with latch

Ordering information

Model Product type Coding Number of contacts Wiring Method
M12-D4-KP-K front-mounted right-angle receptacle, female contacts, unshielded, PCB termination D 04 contacts PCB pins

Technical specifications are subject to final engineering confirmation.
