1. Product Overview & Key FeaturesKJFDG belongs to K Series 2.92mm high frequency RF coaxial connector. It adopts flange mounting structure with microstrip termination, high-grade stainless steel shell for stable performance. Wide frequency coverage up to 40GHz, low VSWR, long mating life, suitable for precision high-frequency test and microwave interconnection scenarios.

2. Technical Specifications

• Model: KJFDG
• Series: K Series 2.92mm RF Coaxial Connector
• Contact Polarity: J = Plug (Male contact)
• Mounting Type: F = Flange mounting
• Termination: D = Microstrip termination
• Shell & Plating: G = High-grade stainless steel
• Characteristic Impedance: 50Ω
• Operating Frequency: DC - 40GHz
• VSWR: ≤ 1.30
• Dielectric Withstand Voltage: 750V
• Mating Cycles: ≥ 500 cycles
• Operating Temperature: -65℃ ~ +125℃

3. Application ScenariosMicrowave test instruments,vector network analyzers,high frequency measurement modules,radar communication equipment,satellite signal systems,automated test platforms.
