Lenze M85AS190S255S0DLC Synchronous Servo Motors

1. Product Overview

2. Core Product Advantages

1. Compact high-power-density structure with optimized motor-load inertia ratio, simplifying servo loop tuning and improving system controllabilityLenze.
2. Ultra-smooth rotational performance with minimized cogging torque to guarantee micron-level positioning accuracy during continuous running.
3. One-Cable-Technology (OCT) digital absolute encoder configuration cuts wiring cost and installation space; optional resolver feedback for cost-oriented projectsLenze.
4. Modular expandable design: pre-installed 24V DC electromagnetic holding brake for load holding during power-off; snap-on rotating plug connectors enable rapid on-site wiring and maintenanceLenze.
5. Smooth seamless housing surface conforms to food-grade hygiene requirement; IP65 main enclosure rating resists dust and splashing liquid in harsh workshop environment.
6. Perfect mechanical matching with Lenze G500/G7X0/G8X0 series precision gearboxes to form integrated geared servo drive unitLenze.

3. Key Technical Parameters

• Rated Power: 7.5kW
• Rated Torque: 24Nm | Peak Torque:71Nm
• Rated Speed:3000rpm | Max Speed:4500rpm
• Rated Voltage:330V | Rated Frequency:250Hz | Rated Current:15.4A
• Brake Spec: 24VDC spring-applied holding brake, brake power 49W
• Shaft: Solid smooth shaft with M10 internal thread, shaft diameter 28mm
• Mount Flange: FF180 flange, pitch circle diameter 215mm
• Protection Class: IP65 main body, IP54 for forced cooling version
• Ambient Operating Temp: ≤40℃ | Net Weight:37kg
• Feedback: Digital multi-turn absolute encoder supporting Hiperface DSL single-cable communication

4. Applicable Industries & Application Scenes

Core Application Industries

Typical Application Scenarios

• Packaging: Vertical form-fill-seal machines, carton sealing & sorting servo axes
• Automation Handling: Palletizing delta robots, automated conveyor positioning drives
• Food Industry: Filling & capping machine feeding servo units (smooth housing meets sanitation standard)
• CNC Equipment: Precision feeding axis for small machining centers
