Schneider XCE106C Cat Whisker Type Universal Actuation IP65 Spring Return Industrial Travel Switch

Product Overview

Core Advantages

• Cat Whisker Multi‑Directional Actuation: Flexible steel wire (Ø1.2 mm) detects contact from all angles; ideal for irregular or moving profiles.
• Spring Return: Automatically resets when contact is lost, enabling repetitive cyclic operation.
• IP65 Protection: Dust‑tight and splash‑proof, suitable for harsh workshop conditions.
• 1NO + 1NC Contact: Combined normally open/closed for flexible circuit design and safety redundancy.
• High Sensitivity & Fast Response: Low actuation force (1.5 N); snap‑action switching at up to 120 cycles/min.
• Compact & Durable: Plastic housing + steel actuator; withstands vibration (10–55 Hz) and impacts (30 gn).
• Easy Installation & Wiring: Surface‑mount; screw terminals for 6–9 mm cables.

Technical Specifications

Application Industries & Scenarios

Main Application Fields

1. Machine Tools: CNC machines, lathes, milling machines for tool positioning and travel limit.
2. Conveying & Logistics: Belt conveyors, sorting lines, AGVs for object detection and end‑stop control.
3. Packaging Machinery: Wrappers, cartoners, labeling machines for irregular product positioning.
4. Automation Assembly: Robotic cells, assembly lines for part presence and soft contact detection.
5. Textile & Printing: Looms, printing presses for roll tension and edge detection.
6. Food & Beverage: Processing lines for gentle contact detection with fragile products.

Image Reference

• Application Photos: Mounted on conveyor frames, machine tool slides, and robotic arms for multi‑directional detection.
• Warehouse Photos: Standard packaging, labeled stock, and quality inspection in industrial warehouses.
