Beckhoff KL3454 Programmable Logic Controller PLC with 4-Channel Analog Input 12 Bit Resolution and Electrical Isolation

1 pcs
MOQ
Negotiable
Price
Beckhoff KL3454 Programmable Logic Controller PLC with 4-Channel Analog Input 12 Bit Resolution and Electrical Isolation
Features Gallery Product Description Chat Now
Features
Specifications
Output Method: Relay
Part Type: Sysmac CPM2A
Processortype: Microprocessor-based
Actual Value: Negotiabled Price
Responsetime: Less Than 10 Ms
Power Supply Voltage: AC240-360V.
Dimensions: 90 X 100 X 75 Mm
Memorycapacity: Varies (e.g., 32KB To 1MB Or More)
Safetyfeatures: Watchdog Timer, Fault Diagnostics
Operating_Temperature: -20°C To 60°C
Scantime: Milliseconds Range, Typically 1-10 Ms
Actual Price: Based On Offer
Compliancestandards: IEC 61131-3, UL, CE
Condition: New Original With Sealed
Output_Type: Relay
Memory_Size: 50 KB
Operatingtemperaturerange: -20°C To 60°C
Controltype: Programmable Logic Controller (PLC)
Output Typt: Relay
CPU_Speed: 100 MHz
Powersupply: 24V DC Or 110/220V AC
Displaytype: LCD Or LED Indicators
Outputtype: Digital And Analog
Manufacturer: Siemens
Output Points: 16DO
Expansioncapability: Supports Multiple I/O Expansion Modules
Part No: MVI56E-MCM
Highlight:

Beckhoff KL3454 PLC analog input module

,

K Bus powered PLC with electrical isolation

,

12 bit resolution programmable logic controller
Basic Infomation
Brand Name: Beckhoff
Model Number: KL3454
Payment & Shipping Terms
Delivery Time: 5-7 days
Payment Terms: T/T
Supply Ability: 10000 pcs
Product Description
I. Core Basic Information
  • Brand / Model: Beckhoff KL3454
  • Product Category: K-bus terminal block, 4-channel single-ended analog input module
  • Signal Type: 4–20 mA industrial standard current signal
  • Power Supply: K-bus powered, no additional independent power supply required
  • Mounting: 35 mm DIN rail (EN 60715), 12 mm wide
  • Product Status: In production, regularly supplied Beckhoff
  • Pluggable Version: KS3454 (pluggable terminal blocks for easy maintenance)
II. Key Technical Parameters
Parameter Value
Number of Input Channels 4 channels (Single-ended)
Signal Range 4–20 mA
Resolution 12 bit
Measurement Error < ±0.3% FS (Full Scale)
Conversion Time Approx. 2 ms / Channels
Input Internal Resistance < 85 Ω
Electrical Isolation K-bus / Signal Side: 500 V DC
K-bus Current Consumption Typical 85 mA
Surge Withstand Voltage 30 V DC
Process Image Inputs: 4 * 16-bit data (optional 4 * 8-bit control / status)
Weight Approx. 55 g
Dimensions 12 mm * 100 mm * 68 mm
Operating Temperature -25 ～ +60°C; Storage: -40 ～ +85°C
Protection Rating IP20
III. Functions and Features
  • 2-Wire Sensor Support: Built-in 24 V power contact allows direct connection of 2-wire 4–20 mA sensors without external power supply.
  • Single-Ended Common Ground: 4 inputs share a common 0 V reference ground for simple wiring.
  • Plug and Play: Beckhoff operates immediately upon power-up, requiring no address or configuration settings.
  • Status Diagnostics: Built-in overload/disconnection detection, with intuitive status indication via RUN/Error LEDs.
  • High-Density Design: 4 channels, only 12 mm wide, suitable for dense installation within control cabinets.
  • Applications: Widely used in PLC/DCS systems to acquire sensor signals such as pressure, flow, level, and temperature (current output type).
