M12 Circular Connector Waterproof Overmolded Cable Assembly M12-A04-BP-M

1 pcs
MOQ
Negotiable
Price
M12 Circular Connector Waterproof Overmolded Cable Assembly M12-A04-BP-M
Features Gallery Product Description Chat Now
Features
Specifications
Integrationcapability: Compatible With MES, ERP Systems
Power Phase Number: Other, Single Phase
Basic Infomation
Model Number: M12-A04-BP-M
Payment & Shipping Terms
Packaging Details: pieces
Delivery Time: 5-8days
Payment Terms: T/T
Supply Ability: 10000 PCS
Product Description
Product Image
Contact Gender
male
Wiring Method
Solder
Mounting Method
panel/PCB mounting
shielded
unshielded
Key Features
Product Overview

The M12 circular sealed connector uses A-coding for mating-error prevention. This configuration is a malesealed threaded panel-mount plug, providing excellent mechanical stability and electrical continuity for durable, reliable connections in harsh industrial environments.

Key Technical specifications
Rated voltage
250V / 60V / 30V
Rated current
4A / 2A / 1.5A
Degree of protection
IP67, when mated
Operating temperature
Connector: -45℃ ~ +115℃
Contact resistance
≤ 3 mΩ
Insulation resistance
≥ 100 MΩ
Mechanical endurance
≥ 500 mating cycles
Rated impulse voltage
500V / 800V / 1500V / 2500V
Shell material
nickel-plated brass / nickel-plated zinc alloy
Insulator material
PA66 (UL 94-V0)
Contact material
gold-plated brass
Dimensional drawing
Product Part-number designationBreakdown
M12

Product type: M12 circular connector

A04

ACoding / 04 contacts (Number of contacts)

BP-M

sealed threaded panel-mount plug

Ordering information
Model Product type Coding Number of contacts Wiring Method
M12-A04-BP-M RJ45 overmolded receptacle, male contacts, unshielded, solder termination A 04 contacts Solder
M12-A05-BP-M Same as above A 05 contacts Solder
M12-A08-BP-M Same as above A 08 contacts Solder
Key Features
  • Standard M12 threaded coupling mechanism, compliant with IEC 61076-2-101
  • Available in unshielded versions, high-strength all-plastic or metal housing, lightweight and durable
  • High-grade flame-retardant PA66 Insulator material, rated UL 94 V-0
  • Heavy gold plating on contact surfaces, ensures low Contact resistance (≤3mΩ) and extended mating life
