BMA-JFD10 High Frequency Microwave Connectors BMA K Series Four Hole Flange Microstrip Plug

1PCS
MOQ
$20.80‑31.80
Price
BMA-JFD10 High Frequency Microwave Connectors BMA K Series Four Hole Flange Microstrip Plug
Features Gallery Product Description Chat Now
Features
Specifications
Installationtype: Panel Mount / DIN Rail Mount
Service: 24 Hours Online Service
Model: 6ES7314-6CH04-0AB0
Tolerance: -
Operating Voltage: 110 V
Highlight:

BMA-JFD10 Microwave Coaxial Connector

,

BMA-JFD10 Four-Hole Microwave Coaxial Connector

,

Four Hole Plug Microwave Coaxial Connector
Basic Infomation
Place of Origin: China
Certification: CE
Model Number: BMA-JFD10
Payment & Shipping Terms
Payment Terms: T/T
Supply Ability: 20PCS 1week
Product Description

BMA-JFD10 Four-Hole Flange Mount Straight Male RF Coaxial Connector 0‑18GHz 50Ohm for Microwave Test

1. Product Overview & Key Features

The BMA-JFD10 is four-hole flange mount microstrip plug of BMA K series high frequency microwave coaxial connector. It is 50Ohm impedance and supports DC~18GHz wide frequency range. With four-hole fixed flange structure, low VSWR and excellent repeatability, it ensures stable high-frequency signal transmission for test and measurement equipment.

2. Technical Specifications

  • Core Specification/Series: BMA K Series
  • Model: BMA-JFD10
  • Impedance: 50Ω
  • Frequency Range: DC - 18GHz
  • Connector Gender: Male
  • Mounting Type: Four-hole flange mount
  • Interface Type: Straight
  • Application: Microstrip plug

3. Application Scenarios

Microwave test instruments,RF measurement systems,communication base station equipment,radar modules,industrial RF testing modules,high frequency signal distribution systems.

Tag:

BMA Connector

High Frequency Microwave Connector

SMA to BMA Adapter
