Product Overview

The M12 circular sealed connector uses A-coding for mating-error prevention. This configuration is a malestraight male connector with cable retention, providing excellent mechanical stability and electrical continuity for durable, reliable connections in harsh industrial environments.

Key Features

  • Standard M12 threaded coupling mechanism, compliant with IEC 61076-2-101
  • Available in unshielded versions, high-strength all-plastic or metal housing, lightweight and durable
  • High-grade flame-retardant PA66 Insulator material, rated UL 94 V-0
  • Heavy gold plating on contact surfaces, ensures low Contact resistance (≤3mΩ) and extended mating life

Key Technical Specifications

Contact Gendermale
Wiring MethodSolder
Mounting Methodpanel/PCB mounting
Shieldedunshielded
Rated voltage250V / 60V / 30V
Rated current4A / 2A / 1.5A
Degree of protectionIP67, when mated
Operating temperatureConnector: -45℃ ~ +115℃
Contact resistance≤ 3 mΩ
Insulation resistance≥ 100 MΩ
Mechanical endurance≥ 500 mating cycles
Rated impulse voltage500V / 800V / 1500V / 2500V
Shell materialnickel-plated brass / nickel-plated zinc alloy
Insulator materialPA66 (UL 94-V0)
Contact materialgold-plated brass

Product Part-number Designation Breakdown

M12Product type: M12 circular connector
A4A Coding / 4 contacts (Number of contacts)
UP-Gstraight male connector with cable retention

Ordering Information

Model Product type Coding Number of contacts Wiring Method
M12-A4-UP-G rear-mounted flange receptacle, male contacts, unshielded, solder termination front-mounted flange receptacle, female contacts, unshielded, solder termination A 04 contacts Solder
M12-A4-NP-V Same as above A 04 contacts Solder
M12-A8-NP-C Same as above A 08 contacts Solder
M12-A17-NP-V Same as above A 17 contacts Solder
M12-A17-NP-C Same as above A 17 contacts Solder
