Product Title

WAIN M12‑A03‑SK M12 A‑Coding Male Straight Cable Plug 3‑Pin Unshielded Solder Connection Circular Connector

Product Overview

The WAIN M12‑A03‑SK is an M12 A‑coding straight male field‑assembly circular connector with 3‑pin contacts, unshielded, solder‑type wiring connection. Designed for field on‑site cable assembly, widely used for industrial sensor and actuator signal wiring. It adopts M12×1 threaded locking structure, achieves IP67 waterproof and dust‑proof performance after proper mating, delivers stable signal transmission under vibration and harsh workshop environment, fits standard automation field‑bus peripheral equipment.

Core Advantages & Key Features

• Field‑assembly Solder Connection Solder‑type contact design, convenient on‑site wiring without special crimping tools, flexible for field installation and maintenance.
• M12 A‑Coding Standard Definition A‑coding keyway, prevents mis‑mating, compatible with worldwide mainstream M12‑A coded female sockets for sensors & actuators.
• IP67 Ingress Protection Reliable sealing structure, dust‑proof and water‑resistant for indoor / outdoor industrial operating conditions after full locking.
• Thread Screw‑Lock Mechanism M12×1 thread locking, anti‑vibration & anti‑loosening, stable connection under mechanical shock and continuous vibration scenarios.
• Compact Straight Housing Straight cable‑outlet structure, small footprint, suitable for narrow cabinet and equipment side mounting space.
• Durable Mechanical Performance More than 500 mating cycles, long service life for repeated plug‑unplug applications.
• Industrial‑grade Wide Temperature Adaptation Works stably within wide temperature range, adaptable for harsh factory working environment.
• Global Industrial Compliance CE, IEC 61076‑2‑101 certified, meets international circular connector standards for global automation projects.

Technical Parameters

Application Industries & Typical Scenarios

Applicable Industries ‑ Industrial Automation ‑ Sensor & Actuator System ‑ Packaging Machinery ‑ Textile Machinery ‑ Robotics ‑ Machine‑tool Equipment ‑ Material Handling Equipment ‑ Test‑bench Automation

Typical Equipment Proximity sensors, photoelectric sensors, pressure transmitters, field‑bus peripheral devices, packaging production‑line signal wiring, textile spinning equipment signal links, automated test‑bench signal connections.

Packing & Logistics Reference

• Original WAIN individual neutral carton packing
• 12‑month manufacturer warranty
• Suitable for bulk export orders, support EXW / DDP shipment.
