FANUC A06B-6140-H015 Dual-Axis Servo Amplifier with High-Precision Control and 17.5 kW Output Power

1
MOQ
225$
Price
FANUC A06B-6140-H015 Dual-Axis Servo Amplifier with High-Precision Control and 17.5 kW Output Power
Features Gallery Product Description Chat Now
Features
Specifications
Actual Value: Negotiabled Price
Applicationindustry: Manufacturing, Process Control, Robotics
Productname: Industrial Control Automation
Responsetime: Less Than 1 Ms
Certifications: CE, UL, RoHS
Communicationprotocols: Modbus, Profibus, Ethernet/IP, OPC UA
Numberofoutputchannels: 16
Type: Automation System
Powersupply: 24V DC, 110V AC, 220V AC
Compliancestandards: CE, UL, RoHS
Inputtypes: Digital Input, Analog Input
Voltage Range: 24 - 240 V AC/DC
Communication Protocol: Modbus, Ethernet/IP, Profibus
Max Current: 5 A
Basic Infomation
Place of Origin: China
Brand Name: FANUC
Certification: 225$
Model Number: A06B-6140-H015
Payment & Shipping Terms
Packaging Details: pieces
Delivery Time: 3-5 days
Payment Terms: T/T
Product Description
FANUC A06B-6140-H015 SERVO AMPLIFIER

The FANUC A06B-6140-H015 is a high-performance, dual-axis servo amplifier module from FANUC's Alpha i (αi) series. Designed for precision motion control in demanding industrial environments, this unit — also designated as the αiSV 15/15 model — provides independent servo control for two axes simultaneously, making it ideal for CNC machine tools, industrial robots, and automated production lines.

As part of FANUC's advanced αiSV series, this amplifier module features high-speed digital control technology, delivering exceptional torque, speed, and position control accuracy. Its compact, space-saving design allows for efficient cabinet integration, while the high-speed FANUC Serial Servo Bus (FSSB) interface enables precise, synchronized control over connected servo motors.

Key Specifications
Parameter Detail
Part Number A06B-6140-H015
Series FANUC Alpha i (αi)
Model Type αiSV 15/15 (Dual-Axis Servo Amplifier)
Number of Axes 2 (Dual Axis)
Rated Input Voltage 200-240 VAC, 3-phase, 50/60 Hz
Main Input Current 63 A at 200V
Rated Output Current (Per Axis) 5.9 A
Rated Output Power 17.5 kW
Output Voltage Range 283-339 VDC
Dimensions (H x W x D) 38 cm x 9 cm x 27.2 cm (approx. 15" x 3.5" x 10.7")
Weight Approx. 6.8 kg (15.0 lbs)
Cooling Method Integrated fan cooling
Mounting Type Panel mount
Communication Interface FANUC Serial Servo Bus (FSSB)
Features & Benefits
  • Dual-axis integration: Controls two servo motors from a single module, reducing cabinet space, wiring complexity, and overall system cost
  • High-precision control: Digital servo technology provides smooth motor operation, fast dynamic response, and micron-level positioning accuracy
  • Energy-efficient operation: Advanced power conversion design lowers power consumption and reduces operating costs
  • Compact, space-saving design: Efficient form factor maximizes cabinet space utilization
  • Built-in diagnostics: Integrated fault detection and LED status indicators enable fast troubleshooting
  • Rugged construction: Industrial-grade components for reliable 24/7 operation in harsh environments
  • Seamless integration: Fully compatible with FANUC Alpha i series servo motors and CNC controllers
Compatible Systems
  • CNC Controllers: FANUC Series 30i, 31i, 32i, 35i, 0i-D/F, and other Alpha i-compatible controllers
  • Servo Motors: FANUC αiS / αiF series servo motors
  • Applications: CNC machining centers, CNC lathes, industrial robots, automated assembly lines, precision positioning systems
Typical Applications
  • CNC machining centers (milling, drilling, tapping)
  • CNC lathes and turning centers with live tooling
  • Industrial robots (material handling, welding, assembly)
  • Automated production and assembly lines
  • Precision grinding and EDM machines
  • Pick-and-place and material handling equipment
  • Packaging machinery
Installation & Maintenance Notes
  • Mounting: Panel mount inside control cabinet (vertical orientation); ensure adequate ventilation clearance
  • Wiring: Connect 3-phase AC input (200-240V) and route high-power DC output to servo motors
  • Cooling: Integrated fan cooling system; inspect and clean散热片 quarterly to prevent overheating
  • Environmental: Operates at 0°C to 40°C (standard range); store at -20°C to 75°C
Important Notes
⚠️ Product Status: The A06B-6140-H015 is a legacy/standard replacement part. Verify availability with authorized FANUC distributors or reputable industrial automation suppliers.
⚠️ Sourcing: Available through industrial automation parts suppliers as new, refurbished, or tested used units. Purchase from vendors offering testing and warranty coverage.
⚠️ Professional Installation: Installation and configuration should be performed by trained FANUC service personnel. Improper wiring or parameter settings can cause equipment damage.
⚠️ Firmware/Compatibility: Ensure compatibility with your specific servo motor models and CNC controller version before installation.
