Schneider XCE102C Steel Roller Plunger Limit Switch

Product Overview

Core Advantages

• Horizontal Steel Roller Plunger: Stainless steel roller for smooth, low‑wear linear actuation from the side.
• Spring Return: Automatically resets when contact is lost, enabling repetitive cyclic operation.
• 1NO + 1NC Contact: Combined normally open/closed for flexible circuit design and safety redundancy.
• IP65 Protection: Dust‑tight and splash‑proof for harsh workshop environments.
• Snap‑Action Switching: Fast, precise response; 120 cycles/min max operating rate.
• Durable Construction: Metal‑alloy housing + steel actuator; withstands vibration and impact.
• Easy Installation & Wiring: Surface‑mount; screw terminals for 6–9 mm cables.

Technical Specifications

Application Industries & Scenarios

Main Application Fields

1. Machine Tools: CNC machines, lathes, milling machines for linear travel limit and tool positioning.
2. Conveying & Logistics: Belt conveyors, sorting lines, AGVs for end‑stop and position control.
3. Packaging Machinery: Wrappers, cartoners, labeling machines for stroke limiting and synchronization.
4. Automation Assembly: Robotic cells, assembly lines for part presence and linear motion control.
5. Material Handling: Cranes, hoists, lifts for safety limit and over‑travel protection.
6. Textile & Printing: Looms, printing presses for roll tension and edge detection.

Image Reference

• Application Photos: Mounted on machine slides, conveyor frames, and robotic arms for horizontal linear detection.
• Warehouse Photos: Standard packaging, labeled stock, and quality inspection in industrial warehouses.
