Schneider LC1D40A ContactorLC1D40A contactor, 40A contactor, 22kW motor contactor, TeSys D LC1D40A, LC1D40AM7C

LC1D40A Core Parameters (TeSys D Series 40A Three-Pole Contactor)

Model Meaning: LC1 = Contactor; D = Three-Pole Standard; 40A = AC-3 Rated 40A

Main Circuit: 3NO; AC-3: 40A/400V; AC-1: 60A; Rated Insulation Voltage: 690V; Impulse Withstand Voltage: 6kV

Applicable Motors: 22kW (400V) / 11kW (220V); 30HP@460V

Auxiliary Contacts: Standard Configuration 1NO+1NC, expandable auxiliary contacts and delay heads
Coil Voltage: AC24/110/220/380V; DC24/48/110V
Common Models: LC1D40AM7C (AC220V), LC1D40AQ7C (AC380V), LC1D40ABDC (DC24V)
Protection: IP20; Operating Temperature: -25℃~+60℃
Mounting: 35mm DIN rail / panel mount; Dimensions: 55mm×85mm×101mm; Weight ≈580g
Lifespan: Mechanical life ≈30 million cycles; AC-3 electrical life ≈1.5–2 million cycles
Certifications: CCC, CE, UL, IEC 60947-4-1, RoHS
Applications: ≤22kW three-phase motors, fans/pumps/air compressors, injection molding machines, PLC cabinets, distribution cabinets, star-delta/reversible starters
