Schneider Electric NSX630 MIC2.3 630A Circuit Breaker with MicroLogic 2.3 Trip Unit for 690V AC Industrial Applications

1 pcs
MOQ
159.5 USD
Price
Schneider Electric NSX630 MIC2.3 630A Circuit Breaker with MicroLogic 2.3 Trip Unit for 690V AC Industrial Applications
Features Gallery Product Description Chat Now
Features
Specifications
Inputvoltage: 24V DC
Outputvoltage: 24V DC
Mounting Type: DIN Rail / Panel Mount
Category: Automation
Softwarecompatibility: Supports SCADA And HMI Software
Inputvoltagerange: 100V To 240V AC
Manufacturer: Siemens
Numberofoutputchannels: 16
Actual Value: Negotiabled Price
Control Type: Programmable Logic Controller (PLC)
Inputtype: Digital And Analog Inputs
Powerconsumption: Less Than 10W
Industry: Manufacturing
Scalability: Modular Design For Easy Expansion
Productname: Industrial Control Automation
Highlight:

630A Circuit Breaker

,

MicroLogic 2.3 Trip Unit Circuit Breaker

,

690V AC Industrial Circuit Breaker
Basic Infomation
Brand Name: Schneider
Model Number: NSX630 MIC2.3 630A
Payment & Shipping Terms
Delivery Time: 5-7 days
Payment Terms: T/T
Supply Ability: 10000 pcs
Product Description
Schneider Electric ComPacT NSX630 MIC2.3 630A Circuit Breaker
High-performance circuit breaker designed for industrial power distribution systems with advanced electronic protection and reliable operation.
Core Specifications
Brand: Schneider Electric
Series: ComPacT NSX
Frame Current: 630A
Rated Current (In): 630A (40℃)
Trip Unit: MicroLogic 2.3 Electronic Trip (LSoI Three-Stage Protection)
Number of Poles: 3P / 4P (3D/4D)
Installation Method: Fixed, Insert, Removable
Complete Model Examples
• NSX630N MIC2.3 630A 3P (LV432893)
• NSX630F MIC2.3 630A 3P (LV432876)
• NSX630H MIC2.3 630A 3P (LV432895)
Electrical Parameters
Parameter Value
Rated Operating Voltage (Ue) 690V AC, 50/60Hz
Rated Insulation Voltage (Ui) 800V AC
Rated Impulse Withstand Voltage (Uimp) 8kV
Breakthrough Capacity (Icu @ 415V) N type: 50kA; F type: 36kA; H type: 70kA
Mechanical Life 15,000 cycles
Electrical Life 8,000 cycles (440V)
Protection Rating IP20 (front)
Weight (3P) Approx. 8.1kg
Dimensions (3P) Approx. 140*255*110mm (W*H*D)
MicroLogic 2.3 Trip Unit Protection Features
  • Long-time Delay Protection (L): Overload protection with current adjustable from 0.4 to 1 * In, inverse time characteristic
  • Short-time Delay Protection (S): Short-circuit short-time delay with current adjustable from 1.5 to 10 * In, delay 0.1 to 0.4 s
  • Instantaneous Protection (I): Short-circuit instantaneous at 14 * In fixed (approximately 8820A)
  • Display: LED status indicator (operating/faulting)
  • Function: Isolation function compliant with IEC 60947-2 standard
Application Scenarios
  • Main circuit and branch circuit protection in industrial power distribution systems
  • Factory, data center, and building distribution panels
  • Motor, transformer, and capacitor bank protection
  • Replaces traditional air switches with precise electronic protection
Certifications and Standards
Standards: IEC 60947-2, GB 14048.2
Certifications: CCC, cULus, CSA, EAC, classification society certifications
