Programmable Logic Controller PLC Featuring Pluggable KS4438 Terminal Blocks for Simplified Maintenance and 8 Channel Output

1 pcs
MOQ
Negotiable
Price
Programmable Logic Controller PLC Featuring Pluggable KS4438 Terminal Blocks for Simplified Maintenance and 8 Channel Output
Features Gallery Product Description Chat Now
Features
Specifications
Output Method: Relay
Part Type: Sysmac CPM2A
Processortype: Microprocessor-based
Actual Value: Negotiabled Price
Responsetime: Less Than 10 Ms
Power Supply Voltage: AC240-360V.
Dimensions: 90 X 100 X 75 Mm
Memorycapacity: Varies (e.g., 32KB To 1MB Or More)
Safetyfeatures: Watchdog Timer, Fault Diagnostics
Operating_Temperature: -20°C To 60°C
Scantime: Milliseconds Range, Typically 1-10 Ms
Actual Price: Based On Offer
Compliancestandards: IEC 61131-3, UL, CE
Condition: New Original With Sealed
Output_Type: Relay
Memory_Size: 50 KB
Operatingtemperaturerange: -20°C To 60°C
Controltype: Programmable Logic Controller (PLC)
Output Typt: Relay
CPU_Speed: 100 MHz
Powersupply: 24V DC Or 110/220V AC
Displaytype: LCD Or LED Indicators
Outputtype: Digital And Analog
Manufacturer: Siemens
Output Points: 16DO
Expansioncapability: Supports Multiple I/O Expansion Modules
Part No: MVI56E-MCM
Input Points: 100-2
Memory: 50 KB
Safetystandards: IEC 61508, ISO 13849
Type: Automation System
Operatingtemperature: -20°C To 60°C
Model: S7-1200
Highlight:

PLC with pluggable terminal blocks

,

8 channel output PLC

,

programmable logic controller for maintenance
Basic Infomation
Brand Name: Beckhoff
Model Number: KL4438
Payment & Shipping Terms
Delivery Time: 5-7 days
Payment Terms: T/T
Supply Ability: 10000 pcs
Product Description
I. Core Basic Information
  • Brand / Model: Beckhoff KL4438
  • Product Category: K-bus terminal block, 8-channel single-ended analog output module
  • Signal Type: ±10 V voltage signal (industrial standard bipolar voltage)
  • Power Supply: K-bus power supply + external 24 V power contacts
  • Mounting: 35 mm DIN rail (EN 60715), 12 mm width
  • Product Status: In production, regularly supplied
  • Pluggable Version: KS4438 (pluggable terminal blocks for easy maintenance) Beckhoff
II. Key Technical Parameters
Parameter Value
Number of Output Channels8 channels (Single-ended) Beckhoff
Signal Range-10 V ～ +10 V Beckhoff
Resolution12 bit Beckhoff
Output Accuracy< ±0.2% FS (Full Scale)
Conversion TimeApprox. 8 ms / channel
Output Load> 5 kΩ (Short Circuit Protection)
Electrical IsolationK-bus / Signal Side: 500 V DC
K-bus Current ConsumptionTypical 20 mA (5 V)
External Power ConsumptionTypical 20 mA (24 V)
Process MappingOutput: 8 * 16 bits data (optional 8 * 8 bits control / status)
WeightApprox. 75 g
Dimensions12 mm * 100 mm * 68 mm
Operating Temperature0 ～ +55°C; Storage: -25 ～ +85°C
Relative Humidity95%, non-condensing
III. Functions and Features
  • Single-ended common ground output: 8 outputs share a common 0 V reference ground, simplifying Beckhoff wiring.
  • Plug and Play: No address or configuration settings required, power-on and it's operational.
  • Status Indication: Independent RUN LED for each channel, clearly displaying the output status (Beckhoff).
  • Short-circuit protection: Built-in short-circuit protection at the output prevents damage to the module due to load failure.
  • High-density design: 8 channels, only 12 mm wide, suitable for dense installation in control cabinets.
  • Application scenarios: Used for controlling inverters, servo drives, proportional valves, recorders, and other equipment requiring ±10 V control signals.
Tag:

PLC Programmable Logic Controller

Industrial PLC Controller

PLC In Industrial Automation
