Beckhoff KL3408 Programmable Logic Controller PLC Mitsubishi Programmable Logic Controller

1 pcs
MOQ
Negotiable
Price
Beckhoff KL3408 Programmable Logic Controller PLC Mitsubishi Programmable Logic Controller
Features Gallery Product Description Chat Now
Features
Specifications
Actual Price: Based On Offer
Compliancestandards: IEC 61131-3, UL, CE
Condition: New Original With Sealed
Output_Type: Relay
Memory_Size: 50 KB
Highlight:

Beckhoff KL3408 PLC module

,

industrial programmable logic controller

,

Mitsubishi PLC controller
Basic Infomation
Brand Name: Beckhoff
Model Number: KL3408
Payment & Shipping Terms
Delivery Time: 5-7 days
Payment Terms: T/T
Supply Ability: 10000 pcs
Product Description
Beckhoff KL3408 8-Channel Analog Input Module | PLC Expansion Bus Terminal | ±10V Voltage Acquisition

1. Product Overview

The KL3408 is a standard K-bus analog input terminal developed by Beckhoff Automation, serving as a core expansion I/O module for Beckhoff PLC & distributed control system.

It collects 8 channels of single-ended -10V ~ +10V analog voltage signals from on-site sensors, transmitters and measuring instruments, converts analog signals into 12-bit digital data via high-precision AD conversion, and uploads isolated digital signals to upper-level PLC/industrial host controllers through K-bus communication.

It realizes real-time monitoring of pressure, temperature, displacement, flow and other analog physical quantities on production lines, and works with other KL series terminals to build compact distributed automation control cabinets.

2. Core Product Advantages


Icon Tag Core Advantage Detailed Explanation
 Ultra Compact Layout High channel density design 8 signal channels integrated into 1 standard 12mm terminal housing, greatly saving cabinet installation space compared with 4-channel modules
Galvanic Isolation Protection 500V electrical isolation Isolate field signal side and bus control side to avoid surge, interference and circuit burnout damage to main PLC equipment
Plug & Play Connection No extra address configuration Automatic identification by bus coupler after DIN rail snapping and wiring, no software address setting required to reduce debugging workload
 Stable Acquisition Precision Low measurement error Total full-scale error less than ±0.3%, stable sampling even under long-distance field wiring
Strong Environmental Adaptability Wide temperature & anti-vibration Meet industrial EMC and vibration shock standards, adapt to factory workshop, outdoor equipment and harsh industrial environments
Visual Working Indicator Built-in status LED LED light intuitively displays bus data exchange status, easy for on-site fault troubleshooting

3. Technical Parameters

Item Specific Specification
Model KL3408
Input Channel Quantity 8 channels, single-ended input
Supported Signal Range -10 V ~ +10 V DC
Input Internal Resistance > 130 kΩ
AD Conversion Resolution 12 Bit (11 Bit for 0~10V signal range)
Single Channel Conversion Time Approx. 4 ms
Max Measurement Error ＜ ±0.3% of full scale value
Electrical Isolation Grade 500 V (between K-bus and field signal)
K-bus Power Consumption Typical 140 mA
Process Image Data Bit 8 × 16-bit input data; optional 8 × 8-bit status control bit
Net Weight Approx. 75 g
Operating Temperature 0 ℃ ~ +55 ℃
Storage Temperature -25 ℃ ~ +85 ℃
Humidity Resistance 95% relative humidity, non-condensing
Protection Class IP20 (indoor cabinet installation only)
Installation Method Standard DIN 35mm rail mounting
Compliance Certifications EN 60068 vibration & shock standard, EN 61000 EMC immunity & emission standard

4. Application Industries & Scenarios

Main Applicable Industries

  1. New Energy Equipment: Solar cell production equipment, lithium battery automated assembly line
  2. Packaging & Printing Machinery: Multi-point pressure and position signal collection for filling & packaging lines
  3. Water Treatment & Environmental Protection: Water quality sensor signal acquisition, pump pressure monitoring
  4. CNC & Machine Tool Industry: Spindle vibration, tool displacement analog signal monitoring
  5. Building Automation & HVAC: Central air conditioning temperature/humidity/valve feedback signal collection
  6. Logistics Automation: Conveyor belt tension, weighing sensor data acquisition

Scene Description for Image Matching

  • Application Scene Picture: Recommend photo of the module plugged into Beckhoff CX series PLC + bus coupler inside the control cabinet, connected to on-site sensor wiring
  • Warehouse Stock Picture: Recommend real photo of bulk KL3408 modules in anti-static packaging & warehouse shelf storage, showing sufficient inventory supply

5. Supplementary Export Compliance Info

  • Brand: Beckhoff (Germany Original)
  • Origin: Germany
  • MOQ: 1 Piece
  • Lead Time: 5-7 working days for in-stock items
  • Warranty: 12 months against manufacturing defects
  • HS Code: 85423190 (Industrial programmable logic controller expansion module)
  • Packing: Individual anti-static bag + carton outer packaging
