INOVANCE IS620PT5R4I-C,IS620PT (Pulse/Analog),3PH 380VAC

INOVANCE IS620PT5R4I‑C

Inovance IS620PT Series AC Servo Drive

1. Product Overview

The IS620PT5R4I‑C belongs to Inovance IS620PT high‑performance AC servo drive series with Pulse / Analog command interface. Rated power 1.5 kW, powered by 3‑phase 380 VAC. It delivers precise position‑speed‑torque control for AC servo motors, suitable for traditional automation equipment without field‑bus communication requirement.

2. Core Features

✅ Control interface: Pulse/Direction + Analog command Supports pulse‑direction position input, analog voltage‑based speed / torque reference, compatible with traditional pulse‑type controllers. ✅ Power specification: 3‑Phase 380 VAC input, rated output current 5.4 A ✅ Encoder support: 20‑bit incremental / 23‑bit multi‑turn absolute encoder Absolute encoder saves homing procedure upon power‑on. ✅ Speed‑loop bandwidth up to 1.2 kHz, fast dynamic response ✅ Built‑in auto‑tuning, inertia identification, resonance suppression function ✅ Protection class IP20, cabinet‑mount installation ✅ CE certified, InoServoShop PC software for parameter configuration & monitoring

3. Technical Specifications

• Model: IS620PT5R4I‑C
• Series: IS620PT (Pulse / Analog control)
• Input Power: 3‑Phase 380 V AC
• Rated Power: 1.5 kW
• Rated Output Current: 5.4 A
• Control Command: Pulse/Direction, Analog input
• Supported Encoder: 20‑bit Incremental / 23‑bit Multi‑turn Absolute
• Protection Degree: IP20
• Installation: Cabinet mounting

4. Application Fields

Packaging machinery, textile machinery, printing equipment, material handling, automated production lines and other motion‑control devices adopting pulse/analog control mode.

5. Package & Warranty

Original unit, individual carton packaging. 12‑month warranty against manufacturing defects.
