Core Hardware Specifications (Mainstream Model: C6025-0000)
1. Processor (8th/11th Gen Core i U Series, Low Power Consumption, High Performance)
Entry-level: Intel Celeron 4305UE (2 cores, 2.0 GHz)
Mainstream: Intel Core i3-8145UE (2 cores) / i5-8365UE (4 cores)
High-end: Intel Core i7-8665UE (4 cores, 1.7 GHz)
Features: Low power U series, fanless for stable operation, performance far exceeding Atom platform
2. Memory and Storage
Memory: 4 GB DDR4 (expandable to 8 GB)
Storage: 1 × M.2 SSD, standard 40 GB, maximum 320 GB
3. Power Supply and Cooling
Power Supply: 24 V DC (22–30 V DC wide voltage)
Cooling: Fully passive fanless, single-sided heatsink; 5 cm clearance required at the top and bottom. Ventilation Space
Housing: Die-cast aluminum-zinc alloy, robust and durable
4. Protection and Safety
Protection Rating: IP20
Safety: Integrated fTPM 2.0 (some models)
III. Interfaces and Communication (C6025-0000)
Ethernet: 2 × 10/100/1000 Mbps RJ45, supports EtherCAT master station
Display: 1 × DisplayPort (4K@30Hz)
USB: 2 × USB 3.0 + 1 × USB-C (some newer versions)
Others: Status LEDs, built-in real-time clock, optional 1-second UPS
IV. Software and System
Operating System: Windows 10/11 IoT Enterprise LTSC, TwinCAT/BSD
Control Software: TwinCAT 3 (full-featured PLC, NC, CNC, IoT, HMI)
Programming: IEC 61131-3, C/C++, .NET, Python, etc.
V. Environment and Certifications
Operating Temperature: 0～ +50℃
Storage temperature: -25～+85℃
Humidity: 5%～95%, non-condensing
Vibration/Shock resistance: Complies with EN 60068-2-6 / EN 60068-2-27
Certifications: CE, UL, cULus
VI. Installation methods: Rear wall mounting, side wall mounting, DIN rail mounting (35mm standard DIN rail)
Interface direction is rotatable to adapt to different wiring configurations
