Home /Products/Programmable Logic Controller PLC/Beckhoff CX5130 PLC Embedded PC Dual Ethernet DIN Rail

Beckhoff CX5130 PLC Embedded PC Dual Ethernet DIN Rail

1 pcs
MOQ
Negotiable
Price
Beckhoff CX5130 PLC Embedded PC Dual Ethernet DIN Rail
Features Gallery Product Description Chat Now
Features
Specifications
Power Supply Voltage: AC240-360V.
Mountingtype: DIN Rail Or Panel Mount
Dimensions: 90 X 100 X 75 Mm
Expansioncapability: Modular Expansion Supported
Highlight:

Beckhoff CX5130 DIN Rail PLC

,

Embedded PC dual Ethernet PLC

,

Beckhoff PLC with DIN Rail
Basic Infomation
Brand Name: Beckhoff
Model Number: CX5130
Payment & Shipping Terms
Delivery Time: 5-7 days
Payment Terms: T/T
Supply Ability: 1000 pcs
Product Description
Beckhoff CX5130 PLC Embedded PC Dual Ethernet DIN Rail
1. Product Overview

The Beckhoff CX5130 is a compact DIN-rail mounted Embedded PC / PC-based PLC controller powered by Intel Atom® E3827 dual-core processor. Running TwinCAT 2 / TwinCAT 3 automation software, it integrates PLC logic control, multi-axis motion control, data acquisition and HMI visualization on a single hardware platform. It connects directly to Beckhoff EtherCAT I/O terminals (E-bus / K-bus), realizing high-speed distributed automation control for machinery and industrial systems.

2. Product Advantages / Key Features
  • Fanless passive cooling design, low power consumption, stable long-term operation
  • Dual independent Gigabit Ethernet ports for network isolation, EtherCAT or IT communication
  • DIN rail mounting, compact cabinet layout, easy installation and maintenance
  • Support TwinCAT real-time runtime: PLC, motion control, safety control & data logging
  • Wide operating temperature range, strong anti-vibration & EMC performance
  • Rich expandable optional interfaces: PROFIBUS, CANopen, RS232/RS488, PROFINET
  • Compatible with E-bus & K-bus I/O terminals, flexible system expansion
3. Technical Specifications
Item Parameter
Model CX5130 Embedded PC (PLC Controller)
Processor Intel Atom® E3827 Dual-Core, 1.75 GHz
RAM 2GB / 4GB DDR3L (depends on order variant)
Storage CFast card slot, Micro SD slot
Ethernet 2 × RJ45 Gigabit Ethernet (10/100/1000 Mbps)
Onboard Interfaces 4 × USB2.0, 1 × DVI-I display interface
I/O Bus Support E-bus / K-bus terminals auto recognition
Power Supply DC 24V (-15% ~ +20%)
Max Power Consumption 14 W
Mounting Standard DIN Rail
Dimension (W×H×D) 142 mm × 100 mm × 92 mm
Weight Approx. 1095 g
Operation Temp -25 ℃ ~ +60 ℃
Protection Grade IP20
Certifications CE, UL, DNV GL
Software TwinCAT 2 / TwinCAT 3 Runtime, Windows Embedded OS
4. Application Industries & Scenarios
  • Packaging machinery
  • Plastic injection & extrusion equipment
  • Woodworking & metal processing machines
  • Printing & textile automation
  • Battery manufacturing equipment
  • Material handling & conveyor systems
  • Building automation & intelligent logistics
  • Energy equipment & renewable control systems
5. Extra Sales Note
  • Supply: Brand new original sealed, sufficient stock
  • Delivery time: Fast shipment after order confirmation
  • Support technical consultation & model matching
  • Compatible full range Beckhoff EtherCAT I/O terminals
