INOVANCE MD310T,MD310T0.75B,0.75,1,3PH AC380-440V(±15%),3.4,2.1,1.5,150,≥96.5,108x128x158,1.1,IP20

1pcs
MOQ
Negotiable
Price
INOVANCE MD310T,MD310T0.75B,0.75,1,3PH AC380-440V(±15%),3.4,2.1,1.5,150,≥96.5,108x128x158,1.1,IP20
Features Gallery Product Description Chat Now
Features
Specifications
Applicationindustry: Manufacturing, Process Control, Robotics
Powerconsumption: 5W To 20W
Power Supply Voltage: 100 – 240VAC.
Category: Automation Systems
Control Type: Programmable Logic Controller (PLC)
Controltype: Programmable Logic Controller (PLC)
Humidityrange: 5% To 95% Non-condensing
Connectivityoptions: Ethernet, RS-485, Wireless
Power Supply: 24V DC / 110V AC / 220V AC
Integrationcapability: SCADA, HMI, MES Systems
Mounting Type: DIN Rail / Panel Mount
Mounting: DIN Rail / Panel Mount
Output Points: 16DO
Operatingtemperaturerange: -20°C To 60°C
Communicationprotocol: Modbus, Ethernet/IP, Profibus
Highlight:

INOVANCE MD310T AC drive

,

MD310T0.75B 3PH inverter

,

380-440V industrial motor controller
Basic Infomation
Place of Origin: China
Brand Name: INOVANCE
Model Number: MD310T0.75B
Document: zl10423.pdf
Payment & Shipping Terms
Delivery Time: 1WEEK
Payment Terms: T/T
Supply Ability: 20PCS 1WEEK
Product Description
Product Specifications
Brand Product Series Model Rated Power(kW) Rated Power(HP) Input Voltage Input Current(A) Output Current(A) Power Capacity(kVA) Recommended Brake Resistor Power(W) Min Brake Resistor Resistance(Ω) Dimensions(WxHxD,mm) Net Weight(kg) Protection Class
Inovance MD310T MD310T0.75B 0.75 1 3PH AC380-440V(±15%) 3.4 2.1 1.5 150 ≥96.5 108x128x158 1.1 IP20
Inovance MD310T MD310T1.5B 1.5 2 3PH AC380-440V(±15%) 5.0 3.8 3.0 150 ≥96.5 108x128x158 1.1 IP20
Inovance MD310T MD310T2.2B 2.2 3 3PH AC380-440V(±15%) 5.8 5.1 4.0 250 ≥96.5 108x128x158 1.3 IP20
Inovance MD310T MD310T3.7B 3.7 5 3PH AC380-440V(±15%) 10.5 9.0 5.9 300 ≥96.5 130x209x164 1.3 IP20
Inovance MD310T MD310T5.5B 5.5 7.5 3PH AC380-440V(±15%) 14.6 13.0 8.9 400 ≥96.5 130x209x164 2.3 IP20
Inovance MD310T MD310T7.5B 7.5 10 3PH AC380-440V(±15%) 20.5 17.0 11.0 500 ≥96.5 140x260x171 2.3 IP20
Inovance MD310T MD310T11B 11.0 15 3PH AC380-440V(±15%) 26.0 25.0 17.0 800 ≥96.5 140x260x171 3.4 IP20
Inovance MD310T MD310T15B 15.0 20 3PH AC380-440V(±15%) 35.0 32.0 21.0 1000 ≥96.5 180x298x176 3.4 IP20
General Parameters
General Parameter Specification
Control Mode V/F Control, Sensorless Vector Control (SVC)
Max Output Frequency SVC:0~300Hz; V/F:0~500Hz
Input Frequency 50/60Hz(±5%)
Starting Torque SVC:0.5Hz/150% rated load; V/F:1.0Hz/100% rated load
Speed Stability Accuracy SVC:±0.5%; V/F:1%
Overload Capacity 120% for 1h; 150% for 1min; 180% for 2s
Communication Standard RS485, Modbus RTU; Optional CANlink
Built-in Function PID Regulator, 16-step Speed, Wobble Control, Multi-motor Switchover
I/O Interface 5DI(1×20kHz high-speed), 2AI; 1×50kHz pulse output, 1DO, 1Relay, 1AO
Operating Temperature 0~50℃
Storage Temperature -20~70℃
Relative Humidity 5~95%RH (Non-condensing)
Mounting Type Panel Mount
Cooling Method Forced Air Cooling
Protection Function Overcurrent/Overvoltage/Undervoltage/Overheat/Phase Loss/Short Circuit Protection
