Beckhoff EL4002 Digital Input Module with 2 Analog Outputs 12-bit Resolution and 500V Electrical Isolation

1 pcs
MOQ
Negotiable
Price
Beckhoff EL4002 Digital Input Module with 2 Analog Outputs 12-bit Resolution and 500V Electrical Isolation
Features Gallery Product Description Chat Now
Features
Specifications
Productname: Programmable Logic Controller
Color: Normal
Supply Voltage Type: AC
Power_Supply: 24 V DC
Number_of_Outputs: 10
Communicationprotocol: Modbus, Ethernet/IP, Profibus
Output Method: Relay
Display: Optional LCD Or LED Indicators
Part Type: Sysmac CPM2A
Processortype: Microprocessor-based
Output Points: 20
Actual Value: Negotiabled Price
Responsetime: Less Than 10 Ms
Power Supply Voltage: AC240-360V.
Dimensions: 90 X 100 X 75 Mm
Highlight:

2 Analog Outputs Digital Input Module

,

12-bit Resolution PLC Input Module

,

500V Electrical Isolation Beckhoff EL4002
Basic Infomation
Brand Name: Beckhoff
Model Number: EL4002
Payment & Shipping Terms
Delivery Time: 5-7 days
Payment Terms: T/T
Supply Ability: 10000 pcs
Product Description
Beckhoff EL4002 Digital Input Module
Technical Specifications
Parameter Value Source/Notes
Number of Channels 2 Analog Outputs (AO) Beckhoff
Output Signal 0–10 V DC Voltage Beckhoff
Resolution 12-bit Beckhoff
Output Accuracy < 0.1% (Full Scale) Beckhoff
Load Capacity > 5 kΩ, with Short Circuit Protection Beckhoff
Electrical Isolation E-Bus / Signal Side 500 V Beckhoff
Power Supply 24 V DC (via power contacts) Beckhoff
Conversion Time Approx. 150 µs Beckhoff
Synchronization Function Supports Distributed Clocks, Synchronization Accuracy < 1 µs Beckhoff
Operating Temperature -25 ℃ to +60 ℃
Protection / Mounting IP20, 35 mm DIN Rail Fit
Weight Approx. 60 g
Certifications CE, CCC, UL, ATEX, etc.
Key Features
  • Precise and Stable: 12-bit resolution combined with low-error output meets the needs of precision control
  • Strong Anti-interference: 500V electrical isolation effectively isolates the bus and signal side, adapting to complex industrial environments
  • High-Efficiency Synchronization: Supports distributed clocks, adapting to multi-axis linkage, synchronous control, and other scenarios
  • High Compatibility: Compatible with ESxxxx series pluggable terminal blocks for convenient wiring; supports TwinCAT software configuration, adapts to the COE protocol, and seamlessly integrates with Beckhoff automation systems
  • Flexible Diagnostics: Equipped with LED indicators to display real-time operating status and channel output status, facilitating rapid fault diagnosis
Typical Applications
Suitable for voltage signal output in industrial automation scenarios, such as servo drive speed/position command output, PLC analog control loops, variable adjustment in process control, as well as precision motion control and production line parameter calibration.
