6ES7193-6AM00-0AA0 Siemens Bus Adapter BA 2xM12 M12 Bus Adapter

Title:Siemens 6ES7193‑6AM00‑0AA0 Bus Adapter BA 2xM12 | PROFINET ET200SP Remote IO Communication Module

The 6ES7193‑6AM00‑0AA0 BA 2xM12 is Siemens SIMATIC ET200SP bus adapter, specially designed for ET200SP distributed remote I/O interface modules. It provides two M12 D‑coding push‑pull sockets for PROFINET Industrial Ethernet connection, built‑in 2‑port switch function. It realizes daisy‑chain PROFINET IO field‑bus wiring for remote I/O stations, connect PLC controller and field distributed I/O modules, complete real‑time industrial data transmission for automation sites. Support push‑pull type and standard screw‑lock M12 PROFINET cables, fit harsh workshop environment with high mechanical vibration requirement.

2. Core Advantages & Key Features

• ✅ 2 × M12 D‑coding Push‑pull Sockets Support both push‑pull quick‑lock and standard screw‑type M12 PROFINET cables, strong mechanical anti‑vibration performance for field workshop application.
• ✅ Integrated 2‑Port Internal Switch Realize PROFINET daisy‑chain wiring, no extra external switch required, simplify cabinet wiring layout.
• ✅ Compact Slim Structure 20 mm narrow width, save DIN‑rail installation space, match ET200SP interface module perfectly.
• ✅ PROFINET IO Real‑time Communication Support PROFINET RT / IRT, 100 Mbit/s industrial ethernet transmission, max cable length up to 100 m per segment.
• ✅ Harsh Environment Adaptability Wide operating temperature range, adapt for factory floor, machine‑side installation; conform to IEC industrial standard.
• ✅ Easy Installation & Replacement Tool‑free plug‑on design for ET200SP IM interface module, hot‑swap friendly for maintenance.
• ✅ Global Certification Complies with CE, RoHS, IEC standards, suitable for global export automation projects.

3. Technical Parameters

4. Application Industries & Typical Scenarios

Applicable Industries

‑ Automotive assembly lines ‑ Packaging machinery ‑ Material conveying equipment ‑ Textile production line ‑ Water treatment & pump control ‑ General factory automation ‑ Machine‑side distributed I/O system

Typical Equipment

ET200SP remote IO station, field‑side distributed signal collection, PROFINET daisy‑chain bus wiring, machine cabinet automation control, production‑line field signal acquisition.

Reference scene for bulk export stocking: Suitable for automation spare‑parts warehouse stocking, bulk FOB / DDP export shipment.

5. Packing & Logistics Reference

‑ Net weight: 45 g / pc ‑ Single carton gross weight: 0.12 kg / pc ‑ Original individual export carton packaging.

Remark: This bus adapter must work together with ET200SP IM155‑6 PN interface module, cannot be used independently.
