Product Title

Siemens 6ES7135-6HB00-0DA1 ET200SP AQ 2xU/I HS Analog Output Module 24V DC

1. Product Overview

The Siemens 6ES7135-6HB00-0DA1 is a high-speed analog output module for SIMATIC ET 200SP distributed I/O system. It provides 2 channels of analog output for voltage or current signals, used to control actuators, valves, VFD and other field devices. Powered by 24V DC, it features high conversion speed and 16-bit high resolution. It adopts distributed remote I/O design, connects to PLC via PROFINET, widely used for high-precision automation control.

2. Core Advantages & Key Features

✅ 2 Channels High-speed Analog Output (AQ 2xU/I HS) Supports both voltage and current signal output, fast conversion cycle for high dynamic control requirements. ✅ 16-bit High Resolution High precision output with error ±0.2%, stable analog signal transmission. ✅ Multiple Signal Ranges Selectable Voltage: ±10V, ±5V, 010V,15V; Current: ±20mA, 020mA,420mA. ✅ Per-channel Diagnostic Function Supports channel-level fault diagnosis, convenient for quick troubleshooting. ✅ Electrical Isolation Design Electrically isolated between module and load side to suppress interference in industrial sites. ✅ RUN-time Reconfiguration & Firmware Update Parameter modification without stopping PLC program, supports firmware upgrade. ✅ Compact ET200SP Hot-swap Module DIN rail installation, compatible with BU type A0 / A1 base unit, easy replacement.

3. Technical Parameters

4. Application Industries & Typical Scenarios

Applicable Industries Packaging machinery, textile industry, printing equipment, chemical processing, water treatment, CNC machine tools, general factory automation.

Typical Equipment Proportional valve control, frequency converter speed regulation, analog actuator control, pressure & flow closed-loop control, remote distributed signal acquisition system.

5. Packing & Logistics

• Individual original carton packaging
• Brand new original in stock; fully tested refurbished units available
• 12-month warranty for brand-new items
• Export documents: commercial invoice, packing list can be supplied for overseas shipment
