Product Title
Siemens 6ES7132-6BD20-0BA0 SIMATIC ET200SP DQ 4x24VDC/2A ST, 4 Digital Outputs, 2A, DC24V Standard Module
Product Description
1. Product Overview
The Siemens 6ES7132-6BD20-0BA0 is a standard digital output module belonging to the SIMATIC ET200SP distributed I/O system. It provides 4-channel PNP digital outputs with 2A per channel, powered by DC24V. This module needs to be used with A0-type base unit (base unit not included). It supports module-level diagnostics, substitute value output, PROFIenergy and firmware update. It is widely applied in distributed automation stations to drive solenoid valves, DC contactors and indicator lamps.
Note: This model is phased out by Siemens, replacement part: 6ES7132-6BD21-0BA0.
2. Core Advantages & Key Features
✅ 4-Channel Digital Output, 2A Per Channel PNP sourcing output; maximum total module current 8A, ideal for solenoid valves, DC contactors and other DC loads.
✅ Module-level Diagnostic Function Detect short circuit, wire break and supply voltage fault; configurable substitute-value output to guarantee safe machine operation.
✅ ET200SP Hot-swap Support Module replacement while the station is running, effectively reduce equipment downtime.
✅ PROFIenergy & Upgradeable Firmware Supports PROFIenergy energy-saving function; firmware can be upgraded via TIA Portal.
✅ I&M Identification & Maintenance Data I&M0~I&M3 data for equipment asset management and traceability.
✅ Flexible Modular Architecture Cooperates with A0 base unit, freely collocates with other ET200SP I/O modules on DIN rail.
✅ Global Industrial Certifications CE certified, IP20 protection class, applicable for global distributed automation projects.
Important: BU-A0 base unit is not included in package and must be ordered separately.
3. Technical Parameters
| Item |
Specification |
| Model |
6ES7132-6BD20-0BA0 |
| Product Name |
ET200SP DQ 4x24VDC/2A ST Digital Output Module |
| Brand |
Siemens |
| Series |
SIMATIC ET200SP |
| Supply Voltage |
DC 19.2~28.8V (Nominal DC24V) |
| Output Type |
4-channel PNP sourcing |
| Per-channel Output Current |
2 A |
| Max Total Module Current |
8 A |
| Required Base Unit |
BU type A0 (sold separately) |
| Color Code |
CC02 |
| Functions |
Module diagnostics, substitute-value output, PROFIenergy, firmware update |
| Protection Class |
IP20 |
| Mounting |
DIN rail (with base unit) |
| Operating Ambient Temp |
0 ℃ ~ +60 ℃ |
| Weight |
Approx. 37 g |
| Successor Model |
6ES7132-6BD21-0BA0 |
4. Application Industries & Typical Scenarios
Applicable Industries
- Packaging Machinery
- Conveying & Logistics Automation
- Automotive Auxiliary Equipment
- Textile Machinery
- Machine Tool Peripheral Control
- Modular Distributed Production Stations
Typical Equipment
Solenoid valve control, DC contactor drive, indicator light control, decentralized signal output for assembly lines.
5. Packing & Logistics
- Original brand-new, separate export carton
- Shockproof & moisture-proof export packaging
- Ready stock available, support DHL / FedEx / sea freight for worldwide shipment
