Schneider TM241CE24R Programmable Logic Controller PLC 5W Power Consumption

1 pcs
MOQ
Negotiable
Price
Schneider TM241CE24R Programmable Logic Controller PLC 5W Power Consumption
Features Gallery Product Description Chat Now
Features
Specifications
Points: 40 (24DI+16DO)
Power_Consumption: 5W
Power Supply Voltage: 100 – 240VAC.
Dimensions: 90 Mm X 100 Mm X 75 Mm
Part Type: Sysmac CPM2A
Part No: 3603T
Number_of_Inputs: 14
Number_of_Outputs: 10
CPU_Speed: 100 MHz
Output Typt: Relay
Application: Oil And Gas Factory
Actual Value: Negotiabled Price
Memory: 512 KB
Supply Voltage Type: AC
Point: 14 (8DI+6DO)
Highlight:

Schneider TM241CE24R

,

Programmable Logic Controller PLC 5W

,

Programmable Logic Controller PLC Schneider
Basic Infomation
Brand Name: Schneider
Certification: Brand new original
Model Number: TM241CE24R
Payment & Shipping Terms
Delivery Time: 5-7days
Payment Terms: T/T
Supply Ability: 10000 pcs
Product Description
Schneider TM241CE24R Programmable Logic Controller
Modicon M241 series PLC with 24V DC input and relay outputs, featuring 256KB memory and comprehensive industrial communication capabilities.
Key Specifications
I/O Configuration: 14 digital inputs (24V DC) + 10 mixed outputs
Power Supply: 100-240V AC (85-264V wide range), 50/60Hz
Memory: 64MB RAM + 128MB Flash, supports SD cards up to 32GB
Processor: Executes >45,000 Boolean instructions per millisecond
Dimensions: 110 × 70 × 90 mm (W×D×H)
Weight: 0.48 kg net
Detailed Technical Specifications
Input/Output Configuration
  • Digital Inputs: 14 channels at 24V DC
  • Fast Inputs: 8 channels supporting high-speed counting up to 100kHz
  • General Inputs: 6 channels, source/sink type
  • Mixed Outputs: 4 fast transistor outputs (NPN, 0.5A/channel) + 6 relay outputs (2A/channel)
Communication Interfaces
  • 1 × Ethernet port (Modbus TCP/IP, EtherNet/IP, Web Server)
  • 2 × Serial ports (RS232/RS485, Modbus RTU)
  • 1 × Mini USB programming port
Performance Features
  • High-speed counting capability up to 100kHz for positioning and speed measurement
  • Fast response times: transistor outputs < 0.1ms, relay outputs < 10ms
  • Built-in real-time clock with replaceable CR2032 lithium battery
  • Flash storage ensures data retention during power loss
  • Built-in web server for remote monitoring and diagnostics
Expansion Capabilities
  • I/O Expansion: Supports up to 14 TM3 series modules
  • Maximum I/O Points: Over 500 points
  • Communication Expansion: TM4 modules for CANopen, Profibus DP protocols
Environmental Specifications
Parameter Specification
Protection Rating IP20
Operating Temperature -10℃ to +55℃ (horizontal) / -10℃ to +50℃ (vertical)
Mounting DIN rail (TH35-7.5/15)
Certifications & Compliance
CE, CSA, CULus, RCM, EAC, DNV-GL, Green Premium
Logistics & Shipping Information
  • Hazard Classification: Class 9 dangerous goods (UN3091)
  • Contains: Built-in electrolytic capacitor and CR2032 button battery
  • Packaging: Original cardboard box
  • Gross Weight: Approximately 0.55-0.65 kg
  • Volume: Approximately 0.000693 m³
Programming & Software
Programmed with EcoStruxure Machine Expert (formerly SoMachine), supporting LD/ST/FBD and other programming languages.
