Product Datasheet: MITSUBISHI QH42P

Compliance Statement

1. Product Overview ⚙️

MITSUBISHI QH42P Mixed Digital Input/Output Module for MELSEC-Q Series PLC

2. Core Advantages & Key Features ✅

1. All-in-One 64-Point Mixed I/O Design


   32 input + 32 output channels integrated on one module, greatly reduces the quantity of separate input/output modules, optimizes layout of electrical control cabinets and cuts wiring cost.
2. Universal Sink Input/Output Circuit


   Full sink type circuit design, compatible with most mainstream 24VDC industrial sensors and miniature loads widely used in global automation workshops.
3. Stable Low-Current Input Detection


   Each input point draws 4mA operating current at 24VDC, ensuring reliable signal recognition for proximity switches, photoelectric sensors and limit switches without signal loss.
4. Precise Load Driving Capacity


   0.1A rated output current per single point, stably drives small loads including signal lights, miniature solenoid valves and relay coils within 12–24VDC voltage range.
5. Built-in Circuit Protection


   Overcurrent and surge suppression circuits equipped on each channel to resist instantaneous voltage impact from motors and frequency converters, preventing module burnout.
6. Real-time Fault Diagnosis Function


   Detects output short-circuit, abnormal input voltage and channel disconnection automatically, feeds corresponding error codes to PLC CPU for quick maintenance.
7. Full Compatibility with Q Series iQ Platform


   Plug-and-play with all MELSEC-Q series base units, perfectly matched with Q03UDVCPU and all Q series CPU modules; parameter configuration supported by GX Works2 / GX Works3 programming software.
8. Compact Single-Slot Installation


   Only one module slot is occupied, effectively saving installation space inside electrical cabinets for medium and large-scale automation lines.

3. Complete Technical Specifications

4. Applicable Industries & Typical Scenarios 📊

Applicable Industries

1. Automotive Assembly Automated Lines
2. Food & Beverage Packaging Machinery
3. Logistics Conveying & Sorting Equipment
4. Plastic Molding & Injection Machines
5. Water Treatment Environmental Equipment
6. Electronic Component Assembly Equipment
7. Textile & Printing Production Lines
8. General Machinery Automation Control Systems

Typical Application Scenarios

1. Signal collection of photoelectric sensors, limit switches and proximity switches on assembly lines; output control of indicator lamps, small solenoid valves and auxiliary relays.
2. Multi-station conveyor interlock logic control, collecting position feedback signals and driving conveying switching actuators.
3. Auxiliary signal processing for packaging machines, detecting material presence signals and triggering mechanical clamping/unclamping actions.
4. Centralized digital signal collection and logic output for small and medium-sized water treatment equipment, controlling drain valves and alarm indicators.

Matching Image & Icon Labels for Layout

1. Application Scenario Diagram 1: Automotive Automated Assembly Production Line


   Icon Mark: 🤖 Assembly Line Automation
2. Application Scenario Diagram 2: Packaging Machine Electrical Control Cabinet


   Icon Mark: 📦 Packaging Equipment Control System
3. Warehouse Stock Photo: Original Mitsubishi Q Series Module Storage Rack


   Icon Mark: 📦 Industrial PLC Components Warehouse
4. Product Outline Graphic: QH42P Module Physical Drawing


   Icon Mark: ⚙️ QH42P Product Appearance

5. Export Compliance Statement
