Home /Products/Industrial Control Automation/Siemens 6ES7214-1AG31-0XB0 SIMATIC S7-1200 CPU 1214C Compact CPU DC/DC/DC

Siemens 6ES7214-1AG31-0XB0 SIMATIC S7-1200 CPU 1214C Compact CPU DC/DC/DC

1PCS
MOQ
Negotiable
Price
Siemens 6ES7214-1AG31-0XB0 SIMATIC S7-1200 CPU 1214C Compact CPU DC/DC/DC
Features Gallery Product Description Chat Now
Features
Specifications
Powersupply: 24V DC / 110V AC / 220V AC
Outputtype: Digital And Analog Outputs
Programminglanguage: Ladder Logic, Function Block Diagram, Structured Text
Responsetime: Less Than 10 Ms
Inputtype: Digital And Analog Inputs
Application: Manufacturing And Process Control
Mountingtype: DIN Rail / Panel Mount
Operatingtemperaturerange: -20°C To 60°C
Compatibility: Supports Integration With SCADA And HMI Systems
Controltype: Programmable Logic Controller (PLC)
Communicationprotocol: Modbus, Ethernet/IP, Profibus
Productname: Industrial Control Automation
Safetyfeatures: Emergency Stop, Overload Protection
Type: Automation System
Highlight:

Siemens 6ES7214-1AG31-0XB0

,

Siemens SIMATIC S7-1200

,

SIMATIC S7-1200 CPU 1214C
Basic Infomation
Place of Origin: Germany
Brand Name: Siemens
Model Number: 6ES7214-1AG31-0XB0
Document: 6ES7214-1AG31-0BX0.pdf
Payment & Shipping Terms
Delivery Time: 1week
Payment Terms: T/T
Supply Ability: 20PCS 1week
Product Description
Product Specifications
Parameter Value
Article Number 6ES7214-1AG31-0XB0
Product Name SIMATIC S7-1200, CPU 1214C, compact CPU, DC/DC/DC
Supply Voltage (L+) 24 V DC
Supply Voltage Range 20.4 ... 28.8 V DC
Input Current (max) 1.5 A at 24 V DC
Inrush Current (max) 12 A at 28.8 V DC
Sensor Supply Voltage (L+) 24 V DC
Sensor Supply Voltage Range 20.4 ... 28.8 V DC
Backplane Bus Current (5 V DC, max) 1600 mA
Power Loss (typical) 12 W
Integrated Digital Inputs (DI) 14 x 24 V DC
Integrated Digital Outputs (DO) 10 x 24 V DC (transistor, 0.5 A per point)
Integrated Analog Inputs (AI) 2 x 0 ... 10 V DC (configurable to 0 ... 20 mA)
High‑Speed Counters 6 (3 x 100 kHz, 3 x 30 kHz)
Pulse Outputs (PTO/PWM) 2 x 100 kHz
Program Memory 75 KB (work memory)
Load Memory 4 MB (integrated)
Micro SD Card Slot Yes (for program transfer, firmware update)
Communication Ports 1 x PROFINET (RJ45), 1 x RS‑485 (integrated)
Supported Protocols PROFINET IO, TCP/IP, ISO‑on‑TCP, Modbus RTU, USS
Programming Languages LAD, FBD, SCL
Cycle Time Monitoring Adjustable
Forcing Function Yes
Diagnostic Buffer Yes
PID Controller Yes
Operating Temperature (horizontal) -20 ... +60 °C
Operating Temperature (vertical) -20 ... +50 °C
Storage/Transport Temperature -40 ... +70 °C
Relative Humidity (operation) 5 ... 95 %, non‑condensing
Operating Altitude -1000 ... +2000 m
Vibration Resistance (IEC 60068‑2‑6) 2 g (wall), 1 g (DIN rail)
Shock Resistance (IEC 60068‑2‑27) 15 g, 11 ms
Dimensions (W x H x D) 110 mm x 100 mm x 75 mm
Weight approx. 415 g
Approvals UL, cULus, FM, RCM, Marine
Tag:

PLC Ethernet Module

Serial Communication Board

Analog Input Module
