Home /Products/Programmable Logic Controller PLC/MITSUBISHI Q04UDVCPU PLC Q Series iQ CPU module;4096 EA;1.9 ns/log. Com.;40k steps;Ethernet;USB;SD

MITSUBISHI Q04UDVCPU PLC Q Series iQ CPU module;4096 EA;1.9 ns/log. Com.;40k steps;Ethernet;USB;SD

1
MOQ
Negotiable
Price
MITSUBISHI Q04UDVCPU PLC Q Series iQ CPU module;4096 EA;1.9 ns/log. Com.;40k steps;Ethernet;USB;SD
Features Gallery Product Description Chat Now
Features
Specifications
Number_of_Outputs: 10
Mounting_Type: DIN Rail
Model: S7-1200
Output Typt: Relay
Power Supply Voltage: 100 – 240VAC.
Application: Oil And Gas Factory
Dimensions: 90 Mm X 100 Mm X 75 Mm
Power_Consumption: 5 W
Points: 40 (24DI+16DO)
Operating_Temperature_Range: -20°C To 60°C
Condition: New Original With Sealed
Memory_Size: 50 KB
Actual Price: Based On Offer
Input_Voltage: 24V DC
Response_Time: 1 Ms
Highlight:

Mitsubishi Q Series PLC module

,

Q04UDVCPU PLC with Ethernet

,

iQ CPU module with USB
Basic Infomation
Brand Name: MITSUBISHI
Model Number: Q04UDVCPU
Document: 52857c14-1121-11e1-98c9-002...ty.pdf
Payment & Shipping Terms
Packaging Details: PIECES
Delivery Time: 5-8DAYS
Payment Terms: T/T
Product Description
MITSUBISHI Q04UDVCPU PLC Q Series iQ CPU Module
Key Features
• 4096 local I/O points (8192 total with remote)
• Ultra-fast 1.9 ns/logical command cycle time
• 40K step program memory capacity
• Built-in Ethernet and USB connectivity
• SD card support for data storage
Technical Specifications
Specification Value
Series MELSEC-Q SERIES
Type UNIVERSAL MODEL QCPU
Program Memory 40K Steps
Local I/O Points 4096
Local + Remote I/O Points 8192
Cycle Time LD 1.9 ns
Cycle Time MOV 3.9 ns
USB Ports 1
Ethernet Ports 1
Internal Current Consumption 0.58 A
Buffer Battery YES
Compliance & Certifications
Standard Status
CE COMPLIANT
UL/cUL COMPLIANT
UKCA COMPLIANT
EAC NON-COMPLIANT
Shipping Approvals ABS, BV, DNV GL, LR, NK, RINA
Physical Dimensions & Weight
Dimension Value
Width 27.4 mm
Height 98 mm
Depth 115 mm
Weight 0.2 kg
Product Life Cycle
Predecessor Model 217900
Serial Number Format QR1
Selling Status Standard
Packaging Materials
Material Weight (g)
Cardboard 55
Other Paper 1
Other Plastic 23
Total Packaging Weight 79 g
Tag:

PLC Programmable Logic Controller

Industrial PLC Controller

PLC In Industrial Automation
