Siemens 6SL3120-2TE13-0AA3 Double Motor Module, Input: 600 V DC, Output: 3-phase 400 V AC, 3 A/3 A

1pcs
MOQ
Negotiable
Price
Siemens 6SL3120-2TE13-0AA3 Double Motor Module, Input: 600 V DC, Output: 3-phase 400 V AC, 3 A/3 A
Features Gallery Product Description Chat Now
Features
Specifications
Actual Price: Based On Offer
ProgrammingLanguage: Ladder Logic, Function Block Diagram, Structured Text
Points: 40 (24DI+16DO)
Weight: 0.2 KG
MemoryCapacity: From 2 KB To 1 MB Or More
Actual Value: Negotiabled Price
Output Points: 16DO
Output Method: Relay
Display: Optional LCD Or LED Indicators
Input Points: 28
Color: Normal
NumberOfI/OPoints: From 8 To 512 Or More
Part Type: Sysmac CPM2A
Model: FX1N-60MR-001
Type: Industrial Digital Computer
Highlight:

Siemens double motor module PLC

,

600V DC input motor module

,

3-phase 400V AC output module
Basic Infomation
Place of Origin: Germany
Brand Name: Siemens
Model Number: 6SL3120-2TE13-0AA3
Document: 6SL3120-2TE21-0AA3.pdf
Payment & Shipping Terms
Delivery Time: 1week
Payment Terms: T/T
Supply Ability: 20PCS 1week
Product Description
Siemens 6SL3120-2TE13-0AA3 Double Motor Module
Product Overview
Status: Discontinued (Spare Part Only)
Successor Model: 6SL3120-2TE13-0AA4
Electrical Specifications
Input: 600 V DC
Output: 3-phase 400 V AC
Current: 3 A / 3 A (dual axis)
Physical Characteristics
Frame Size: Booksize D-type
Cooling: Internal Air Cooling (29.6 m³/h)
Dimensions: 50 × 270 × 200 mm
Weight: 5.75 kg
Detailed Technical Specifications
Parameter Value
Product Series SINAMICS S120
Order Number 6SL3120-2TE13-0AA3
Product Type Double Motor Module (2-axis)
Electrical Input Specifications
Parameter Value
DC Link Voltage (Nominal) 600 V DC
DC Link Voltage Range 510 - 720 V DC
DC Link Capacitance 220 µF
Overvoltage Threshold 820 V DC ±2%
Undervoltage Threshold 380 V DC ±2%
Electronics Supply Voltage 24 V DC (20.4 - 28.8 V DC)
Electronics Supply Current 1.15 A
Output Specifications (Per Axis)
Parameter Value
Output Voltage 0 ... 0.717 × DC Link Voltage
Output Current (Rated, I_N) 3 A AC
Output Current (Base Load, I_H) 2.6 A AC
Output Current (Intermittent, I_S) 3.5 A AC (40% duty cycle)
Output Current (Peak, I_max) 6 A AC (for 3 sec)
DC Link Current (Rated, I_d) 3.6 A DC
Output Power (Rated) 1.6 kW @ 400 V
Output Power (Base Load) 1.4 kW @ 400 V
Output Frequency 0 - 550 Hz (standard)
Performance & Mechanical Data
Parameter Value
Total Power Loss 97.6 W
Max Pulse Frequency 4 kHz (no derating), up to 16 kHz (with derating)
Width 50 mm
Height 270 mm
Depth 200 mm
Weight Approx. 5.75 kg
Mounting DIN Rail or Screw Mounting
Environmental Conditions
Parameter Value
Operating Temperature 0°C to +40°C (no derating), up to 55°C (with derating)
Storage Temperature -25°C to +70°C
Relative Humidity 5% to 95% (non-condensing)
Altitude Up to 2000 m above sea level (no derating)
Protection Class IP20 (enclosed in cabinet)
Interfaces & Control Features
  • DRIVE-CLiQ Interface: 1 port (included cable)
  • Safety Integrated Functions: STO (Safe Torque Off), SS1, SBC, SLS, SSM (extended)
  • Pulse Pattern: Optimized Pulse Pattern
  • Control Modes: V/f control, Vector control, Servo control
Standards & Approvals
  • CE Mark: Yes
  • UL Certification: Yes
  • CSA Certification: Yes
  • RoHS Compliance: Yes
