Home /Products/Programmable Logic Controller PLC/Siemens 6SL3120-1TE32-0AA3 Single Motor Module, Input: 600 V DC, Output: 3-phase 400 V AC, 200 A

Siemens 6SL3120-1TE32-0AA3 Single Motor Module, Input: 600 V DC, Output: 3-phase 400 V AC, 200 A

1pcs
MOQ
Negotiable
Price
Siemens 6SL3120-1TE32-0AA3 Single Motor Module, Input: 600 V DC, Output: 3-phase 400 V AC, 200 A
Features Gallery Product Description Chat Now
Features
Specifications
Power Supply Voltage: AC240-360V.
Operating_Temperature_Range: -20 To 60 °C
Input Points: 36DI
Number_of_Inputs: 14
Weight: 0.5 Kg
Part Type: Sysmac CPM2A
Output Method: Relay
Output Typt: Relay
Supply Voltage Type: AC
Manufacturer: Siemens
Condition: New Original With Sealed
Memory_Capacity: 50 KB
Application: Spinning Machine, Conveyer Belt
Power_Consumption: 5 W
Input_Voltage: 24 V DC
Highlight:

Siemens single motor module 200A

,

PLC motor module 600V DC input

,

3-phase 400V AC motor module
Basic Infomation
Place of Origin: Germany
Brand Name: Siemens
Model Number: 6SL3120-1TE32-0AA3
Document: 6sl3120-1te32-0aa3.pdf
Payment & Shipping Terms
Delivery Time: 1week
Payment Terms: T/T
Supply Ability: 20PCS 1week
Product Description
Siemens 6SL3120-1TE32-0AA3 Single Motor Module
Input: 600 V DC
Output: 3-phase 400 V AC, 200 A
Format: Booksize
Cooling: Internal Air Cooling
Includes: DRIVE-CLiQ cable
Product Status: Discontinued (Spare Part Only) - Successor: 6SL3120-1TE32-0AA4
General Information
ParameterValue
Product SeriesSINAMICS S120
Order Number6SL3120-1TE32-0AA3
Frame SizeBooksize
Cooling TypeInternal Air Cooling
Electrical Specifications
ParameterValue
DC Link Voltage (Nominal)600 V DC
DC Link Voltage Range510 - 720 V DC
Overvoltage Threshold820 V DC ±2%
Undervoltage Threshold380 V DC ±2%
Electronics Supply Voltage24 V DC (20.4 - 28.8 V DC)
Electronics Supply Current1.5 A (Max)
Output Performance
ParameterValue
Output Voltage0 ... 0.717 × DC Link Voltage
Output Current (Rated, I_N)200 A AC
Output Current (Base Load, I_H)141 A AC
Output Current (Peak, I_max)600 A AC (for 3 sec)
DC Link Current (Rated, I_d)240 A DC
Output Power (Rated)107 kW @ 400 V
Output Power (Base Load)76 kW @ 400 V
Output Frequency0 - 550 Hz (standard)
Mechanical Data
ParameterValue
Dimensions (W×H×D)300 × 380 × 270 mm
WeightApprox. 25 kg
MountingDIN Rail or Screw Mounting
Airflow0.144 m³/s
Sound Pressure Level (1m)73 dB
Interfaces & Features
ParameterValue
DRIVE-CLiQ Interface1 port (included cable)
Safety Integrated FunctionsSTO, SS1, SBC, SLS, SSM (extended)
Control ModesV/f control, Vector control, Servo control
Max. Motor Cable Length (Shielded)100 m
Max. Motor Cable Length (Unshielded)150 m
Environmental Conditions
ParameterValue
Operating Temperature0°C to +40°C (no derating)
Storage Temperature-25°C to +70°C
Relative Humidity5% to 95% (non-condensing)
AltitudeUp to 2000 m above sea level (no derating)
Protection ClassIP20 (enclosed in cabinet)
Power Loss
ParameterValue
Typical Power Loss2.03 kW
Maximum Power Loss2.09 kW
Standards & Approvals
ParameterValue
CE MarkYes
UL CertificationYes
CSA CertificationYes
RoHS ComplianceYes
