Siemens 6SL3120-1TE26-0AC0 Single Motor Module
Input: 600 V DC, Output: 3-phase 400 V AC, 60 A - Booksize C-type with Internal Air Cooling
Product Overview
Product Series: SINAMICS S120
Order Number: 6SL3120-1TE26-0AC0
Product Status: Active (Successor of 6SL3120-1TE26-0AA3)
Frame Size: Booksize C-type
Cooling Type: Internal Air Cooling (0.023 m³/s)
Electrical Specifications
Input Specifications
DC Link Voltage (Nominal): 600 V DC
DC Link Voltage Range: 510 - 720 V DC
Overvoltage Threshold: 820 V DC ±2%
Undervoltage Threshold: 380 V DC ±2%
Electronics Supply Voltage: 24 V DC (20.4 - 28.8 V DC)
Electronics Supply Current (Max): 1.2 A
Output Specifications
Output Voltage: 0 ... 0.717 × DC Link Voltage
Output Current (Rated, I_N): 60 A AC
Output Current (Peak, I_max): 180 A AC (for 3 sec)
DC Link Current (Rated, I_d): 72 A DC
Output Power (Rated): 32 kW @ 400 V
Output Frequency: 0 - 550 Hz (standard)
Control Modes: V/f control, Vector control, Servo control
Mechanical Specifications
Dimensions (W×H×D): 100 mm × 380 mm × 270 mm
Weight: Approx. 8.6 kg
Mounting: DIN Rail or Screw Mounting
Protection Class: IP20 (UL open type)
Sound Pressure Level (1m): 71 dB
Power Loss (Typ./Max): 0.55 kW / 0.62 kW
Environmental Conditions
Operating Temperature: 0°C to +40°C (no derating)
Storage Temperature: -25°C to +70°C
Relative Humidity: 5% to 95% (non-condensing)
Altitude: Up to 2000 m above sea level (no derating)
Interfaces & Features
DRIVE-CLiQ Interface: 1 port (included cable)
Optimized Pulse Pattern: Yes
Motor Connection: M6 bolt (X1), 3-50 mm² cable
Max Motor Cable Length: 100 m (shielded)
Safety Integrated Functions
- Safe Torque Off (STO) - Yes (SIL 2 / PL d)
- SS1 (Safe Stop 1) - Yes
- SBC (Safe Brake Control) - Yes
- SLS (Safe Limited Speed) - Yes
- SSM (Safe Speed Monitor) - Yes
Standards & Approvals
CE Mark: Yes
UL Certification: Yes
CSA Certification: Yes
RoHS Compliance: Yes
Safety Rating: SIL 2 (IEC 61508), PL d (EN ISO 13849-1)
