Name: Siemens 6SL3120-1TE26-0AA3 Single Motor Module, Input: 600 V DC, Output: 3-phase 400 V AC, 60 A
Brand: Shaanxi Qindiyuan Environmental Protection Equipment Co., Ltd.
SKU: 6SL3120-1TE26-0AA3
Availability: InStock

Features Gallery Product Description Chat Now

Features

Specifications

Input Points: 36DI

Condition: New Original With Sealed

MemoryCapacity: Varies (e.g., 32KB To 1MB Or More)

Actual Price: Based On Offer

NumberOfI/OPoints: Varies (e.g., 8 To 512 Or More)

CommunicationInterfaces: Ethernet, RS-232, RS-485, Modbus, Profibus

Part No: 200-595-072-122 VM600 CPUM

ProgrammingLanguage: Ladder Logic, Function Block Diagram, Structured Text

SafetyFeatures: Watchdog Timer, Fault Diagnostics

Output Method: Transistor

InputType: Digital And Analog

ProcessorType: Microprocessor-based

OperatingTemperature: -20°C To 60°C

Weight: 0.68 KG

Output Typt: Relay

Highlight:

Siemens single motor module 60A

PLC motor module 600V DC

3-phase motor module 400V AC

Basic Infomation

Place of Origin: Germany

Brand Name: Siemens

Model Number: 6SL3120-1TE26-0AA3

Document: sie6sl3120-1te26-0aa3_en.pdf

Payment & Shipping Terms

Delivery Time: 1WEEK

Payment Terms: T/T

Supply Ability: 20PCS 1WEEK

Gallery

Siemens 6SL3120-1TE26-0AA3 Single Motor Module, Input: 600 V DC, Output: 3-phase 400 V AC, 60 A

Product Description

Siemens 6SL3120-1TE26-0AA3 Single Motor Module

Product Status: Discontinued (Spare Part Only) - Successor: 6SL3120-1TE26-0AC0

Product Overview

Parameter	Value
Product Series	SINAMICS S120
Order Number	6SL3120-1TE26-0AA3
Product Description	Single Motor Module, Input: 600 V DC, Output: 3-phase 400 V AC, 60 A, Booksize, Internal Air Cooling, includes DRIVE-CLiQ cable
Frame Size	Booksize
Cooling Type	Internal Air Cooling (Built-in fan)

Electrical Input Specifications

Parameter	Value
DC Link Voltage (Nominal)	600 V DC
DC Link Voltage Range	510 - 720 V DC
DC Link Capacitance	1410 µF
Overvoltage Threshold	820 V DC ±2%
Undervoltage Threshold	380 V DC ±2%
Electronics Supply Voltage	24 V DC (20.4 - 28.8 V DC)
Electronics Supply Current (Max)	1.2 A
Electronics Supply Current (Typical)	1.05 A

Output Specifications

Parameter	Value
Output Voltage	0 ... 0.717 × DC Link Voltage
Output Current (Rated, I_N)	60 A AC
Output Current (Base Load, I_H)	51 A AC
Output Current (Intermittent, I_S6)	80 A AC (40% duty cycle)
Output Current (Peak, I_max)	113 A AC
DC Link Current (Rated, I_d)	72 A DC
Output Power (Rated)	32 kW @ 400 V
Output Power (Base Load)	27 kW @ 400 V
Output Frequency	0 - 550 Hz (standard)
Pulse Frequency	4 kHz (standard); 16 kHz (with derating)
Power Loss (Typ./Max.)	0.55 kW / 0.62 kW

Mechanical Data

Parameter	Value
Width	150 mm
Height	380 mm
Depth	270 mm
Weight	9.0 kg
Mounting	DIN Rail or Screw Mounting
Protection Class	IP20 (UL open type)
Sound Pressure Level (1m)	65 dB

Environmental Conditions

Parameter	Value
Operating Temperature	0°C to +40°C (no derating); up to +55°C (derated)
Storage Temperature	-25°C to +70°C
Relative Humidity	5% to 95% (non-condensing)
Altitude	Up to 2000 m above sea level (no derating)

Interfaces & Features

Parameter	Value
DRIVE-CLiQ Interface	1 port (included cable)
Motor Brake Connection	X11 plug-in connector, 24 V DC, 2 A
PE Connection	M6 screw on housing
Safety Integrated Functions	STO, SS1, SBC, SLS, SSM (extended)
Pulse Pattern	Optimized Pulse Patterns
Control Modes	V/f control, Vector control, Servo control

Standards & Approvals

Parameter	Value
CE Mark	Yes
UL Certification	Yes
CSA Certification	Yes
RoHS Compliance	Yes
