Home /Products/Programmable Logic Controller PLC/Siemens 6SL3120-1TE23-0AC0 Single Motor Module, Input: 600 V DC, Output: 3-phase 400 V AC, 30 A

Siemens 6SL3120-1TE23-0AC0 Single Motor Module, Input: 600 V DC, Output: 3-phase 400 V AC, 30 A

1PCS
MOQ
Negotiable
Price
Siemens 6SL3120-1TE23-0AC0 Single Motor Module, Input: 600 V DC, Output: 3-phase 400 V AC, 30 A
Features Gallery Product Description Chat Now
Features
Specifications
Output Points: 24 Points.
Productname: Programmable Logic Controller (PLC)
Model: CP1L-M40DR-A
Expandability: Supports Expansion Modules For Additional I/O Or Communication
Function: Industrial Digital Computer Used For Automation Of Electromechanical Processes
Application: Oil And Gas Factory
Color: Normal
Programminglanguage: Ladder Logic, Function Block Diagram, Structured Text, Instruction List, Sequential Function Chart
Power Supply Voltage: 100 – 240VAC.
Powersupply: Typically 24V DC Or 120/240V AC
Input Points: 36 Points.
Supply Voltage Type: AC
Operatingtemperature: -20°C To 60°C
Actual Price: Based On Offer
Reliability: High Reliability With Industrial-grade Components
Highlight:

Siemens single motor module 30A

,

PLC motor module 600V DC

,

3-phase 400V AC motor module
Basic Infomation
Place of Origin: Germany
Brand Name: Siemens
Model Number: 6SL3120-1TE23-0AC0
Document: 6SL3120-1TE23-0AC0_datashee...en.pdf
Payment & Shipping Terms
Delivery Time: 1WEEK
Payment Terms: T/T
Supply Ability: 20PCS 1WEEK
Product Description
Siemens 6SL3120-1TE23-0AC0 Single Motor Module
Input: 600 V DC | Output: 3-phase 400 V AC, 30 A | Booksize C-type with Internal Air Cooling
Product Overview
Parameter Value
Product Series SINAMICS S120
Order Number 6SL3120-1TE23-0AC0
Product Status Active Product (PM300)
Frame Size Booksize C-type
Cooling Type Internal Air Cooling (0.016 m³/s)
Electrical Input
DC Link Voltage 600 V DC (510-720 V DC range)
DC Link Capacitance 705 µF
Overvoltage Threshold 820 V DC ±2%
Undervoltage Threshold 380 V DC ±2%
Electronics Supply 24 V DC (20.4-28.8 V DC), 0.80 A
Output Specifications
Output Voltage 0 ... 0.717 × DC Link Voltage
Output Current (Rated) 30 A AC
Output Current (Base Load) 25.5 A AC
Output Current (Peak) 56 A AC
Output Power (Rated) 16.0 kW @ 400 V
Output Frequency 0 - 550 Hz
Rated Pulse Frequency 4.0 kHz
Mechanical Data
Dimensions (W×H×D) 60 × 270 × 200 mm
Weight Approx. 5.5 kg
Mounting DIN Rail or Screw Mounting
Environmental Conditions
Operating Temperature 0°C to +40°C (no derating)
Storage Temperature -25°C to +70°C
Relative Humidity 5% to 95% (non-condensing)
Altitude Up to 2000 m above sea level (no derating)
Protection Class IP20 (enclosed in cabinet)
Interfaces & Features
  • DRIVE-CLiQ Interface: 1 port (includes cable)
  • Safety Integrated Functions: STO, SS1, SBC, SLS, SSM (extended)
  • Pulse Pattern: Optimized Pulse Pattern
  • Control Modes: V/f control, Vector control, Servo control
Standards & Approvals
  • CE Mark: Yes
  • cULus Certification: Yes
  • SIL 2 (IEC 61508): Yes
  • PL d (EN ISO 13849-1): Yes
  • Category 3 (EN ISO 13849-1): Yes
  • RoHS Compliance: Yes
Tag:

PLC Programmable Logic Controller

Industrial PLC Controller

PLC In Industrial Automation
