Home /Products/Programmable Logic Controller PLC/Siemens 6SL3120-1TE23-0AA3 Single Motor Module, Input: 600 V DC, Output: 3-phase 400 V AC, 30 A

Siemens 6SL3120-1TE23-0AA3 Single Motor Module, Input: 600 V DC, Output: 3-phase 400 V AC, 30 A

1PCS
MOQ
Negotiable
Price
Siemens 6SL3120-1TE23-0AA3 Single Motor Module, Input: 600 V DC, Output: 3-phase 400 V AC, 30 A
Features Gallery Product Description Chat Now
Features
Specifications
Actual Value: Negotiabled Price
Output Typt: Relay
Part No: F4-04DA
Part Type: Sysmac CPM2A
Power Supply Voltage: AC240-360V.
Actual Price: Negotiabled
Mounting_Type: DIN Rail
Memory_Capacity: 50 KB
Supply Voltage Type: AC
Manufacturer: Siemens
Operating_Temperature_Range: -20°C To 60°C
Dimensions: 90 Mm X 100 Mm X 75 Mm
Condition: New Original With Sealed
Application: Oil And Gas Factory
Output Points: 20
Highlight:

Siemens single motor module 30A

,

PLC motor module 600V DC input

,

3-phase 400V AC motor module
Basic Infomation
Place of Origin: Germany
Brand Name: Siemens
Model Number: 6SL3120-1TE23-0AA3
Document: 6SL31201TE130AA3 (1).pdf
Payment & Shipping Terms
Delivery Time: 1week
Payment Terms: T/T
Supply Ability: 20PCS 1week
Product Description
Siemens 6SL3120-1TE23-0AA3 Single Motor Module
High-performance single motor module with 600 V DC input and 3-phase 400 V AC output at 30 A. Booksize format with internal air cooling and integrated DRIVE-CLiQ interface. Discontinued (Spare Part Only)
Key Specifications
Input Voltage
600 V DC (510 - 720 V DC range)
Output Current
30 A AC (Rated), 56 A AC (Peak for 3 sec)
Output Power
16 kW @ 400 V (Rated)
Cooling System
Internal Air Cooling (56 m³/h airflow)
Dimensions
100 × 280 × 420 mm (W×H×D)
Weight
Approx. 7.0 kg
Electrical Specifications
Parameter Value
DC Link Voltage (Nominal) 600 V DC
DC Link Voltage Range 510 - 720 V DC
DC Link Capacitance 705 µF
Overvoltage Shutdown 820 V DC ±2%
Undervoltage Shutdown 380 V DC ±2%
Electronics Supply Voltage 24 V DC (20.4 - 28.8 V DC)
Electronics Supply Current Typ. 0.85 A
Output Voltage Range 0 ... 0.717 × DC Link Voltage
Output Frequency 0 - 550 Hz (standard)
Power Dissipation 309.2 W
Current Ratings
Load Type Current Rating
Rated Current (I_N) 30 A AC
Base Load Current (I_H) 25.5 A AC
S6 40% Duty Cycle (I_S6) 40 A AC
Peak Current (I_max) 56 A AC (for 3 sec)
DC Link Current (Rated) 36 A DC
Power Output
Load Condition Power Output
Rated Power 16 kW @ 400 V
Base Load Power 13.7 kW @ 400 V
Advanced Features
  • DRIVE-CLiQ Interface with included cable
  • Safety Integrated Functions: STO, SS1, SBC, SLS, SSM (extended)
  • Optimized Pulse Pattern technology
  • Multiple Control Modes: V/f, Vector, and Servo control
  • Regenerative Braking capability
Environmental Specifications
Parameter Specification
Operating Temperature 0°C to +40°C (no derating)
Storage Temperature -25°C to +70°C
Relative Humidity 5% to 95% (non-condensing)
Operating Altitude Up to 2000 m above sea level (no derating)
Protection Class IP20 (enclosed in cabinet)
Certifications & Compliance
  • CE Mark Certified
  • UL Certified
  • CSA Certified
  • RoHS Compliant
  • Country of Origin: Germany
Product Series Information
Part of the SINAMICS S120 series in Booksize format, designed for industrial motor control applications requiring high precision and reliability.
