Home /Products/Programmable Logic Controller PLC/Siemens 6SL3120-1TE21-8AC0 Single Motor Module, Input: 600 V DC, Output: 3-phase 400 V AC, 18 A

Siemens 6SL3120-1TE21-8AC0 Single Motor Module, Input: 600 V DC, Output: 3-phase 400 V AC, 18 A

1
MOQ
Negotiable
Price
Siemens 6SL3120-1TE21-8AC0 Single Motor Module, Input: 600 V DC, Output: 3-phase 400 V AC, 18 A
Features Gallery Product Description Chat Now
Features
Specifications
Scantime: Typically 1ms To 10ms
Output Method: Transistor
Productname: Programmable Logic Controller (PLC)
Applicationareas: Manufacturing Automation, Process Control, Robotics, Building Automation
Powersupply: Typically 24V DC Or 120/230V AC
Programminglanguage: Ladder Logic, Function Block Diagram, Structured Text, Instruction List, Sequential Function Chart
Reliability: High, Designed For Industrial Environments With Resistance To Vibration, Temperature, And Electrical Noise
Model: FX3U-64MT/ES-A
Operatingtemperaturerange: -20°C To 60°C
Points: 40 (24DI+16DO)
Condition: New Original With Sealed
Weight: 1.25 KG
Memorycapacity: Varies By Model, Typically From 2KB To 1MB
Color: Normal
Part Type: Sysmac CPM2A
Highlight:

Siemens single motor module 18A

,

PLC motor module 600V DC input

,

3-phase 400V AC motor module
Basic Infomation
Place of Origin: Germany
Brand Name: Siemens
Model Number: 6SL3120-1TE21-8AC0
Document: 6SL3120-1TE21-8AC0_datashee...en.pdf
Payment & Shipping Terms
Delivery Time: 1week
Payment Terms: T/T
Supply Ability: 20PCS 1week
Product Description
Siemens 6SL3120-1TE21-8AC0 Single Motor Module
Product Overview

SINAMICS S120 Single Motor Module with 600 V DC input and 3-phase 400 V AC output, rated at 18 A. Booksize C-type design with internal air cooling and integrated DRIVE-CLiQ cable.

Key Specifications
Input Voltage
600 V DC (510-720 V DC range)
Output Current
18 A AC (rated)
Output Power
9.7 kW @ 400 V (rated)
Frame Size
Booksize C-type
Electrical Specifications
Parameter Value
DC Link Voltage Range 510 - 720 V DC
DC Link Capacitance 220 µF
Overvoltage Threshold 820 V DC ±2%
Undervoltage Threshold 380 V DC ±2%
Electronics Supply 24 V DC (20.4 - 28.8 V DC), 0.75 A
Output Performance
Parameter Value
Output Voltage 0 ... 0.717 × DC Link Voltage
Output Current (Base Load) 15.3 A AC
Output Current (S6 Duty, 40%) 22 A AC
Output Current (Peak) 36 A AC
DC Link Current (Rated) 20 A DC
Output Power (Base Load) 8.2 kW @ 400 V
Frequency Control Ranges
  • V/f Control: 0 - 600 Hz
  • Vector Control: 0 - 300 Hz
  • Servo Control: 0 - 650 Hz
  • Pulse Frequency: 4.0 kHz
Mechanical Data
Dimension Value
Width 50 mm
Height 270 mm
Depth 380 mm
Weight 4.6 kg
Mounting DIN Rail or Screw Mounting
Protection Class IP20 (UL open type)
Environmental Conditions
Parameter Value
Operating Temperature 0°C to +40°C
Storage Temperature -25°C to +70°C
Relative Humidity 5% to 95% (non-condensing)
Altitude Up to 1000 m above sea level (no derating)
