Name: Siemens 6ES7135-4MB02-0AB0 SIMATIC DP Electronics Module 2 AO I High Feature for ET 200S
Brand: Shaanxi Qindiyuan Environmental Protection Equipment Co., Ltd.
SKU: 6ES7135-4MB02-0AB0
Availability: InStock

Features Gallery Product Description Chat Now

Features

Specifications

Number_of_Inputs: 14

Part Type: Sysmac CPM2A

Weight: 0.5 Kg

Dimensions: 90 X 100 X 75 Mm

Color: Normal

Memory_Capacity: 50 KB

Output Method: Relay

Input_Voltage: 24 V DC

Output Points: 24DO

Power_Consumption: 5 W

Number_of_Outputs: 10

Application: Oil And Gas Factory

Output Typt: Relay

Operating_Temperature_Range: -20°C To 60°C

Actual Price: Negotiabled

Highlight:

Siemens SIMATIC DP electronics module

ET 200S 2 AO I module

PLC high feature analog output

Basic Infomation

Place of Origin: Germany

Brand Name: Siemens

Model Number: 6ES7135-4MB02-0AB0

Document: 6ES71354MB020AB0_datasheet_...en.pdf

Payment & Shipping Terms

Delivery Time: 5-7days

Payment Terms: T/T

Supply Ability: 20pcs 1week

Gallery

Siemens 6ES7135-4MB02-0AB0 SIMATIC DP Electronics Module 2 AO I High Feature for ET 200S

Product Description

SIMATIC DP Electronics Module 2 AO I High Feature for ET 200S

Product Overview

Order Number	6ES7135-4MB02-0AB0
Product Series	Siemens SIMATIC ET 200S Distributed I/O System
Module Type	2-channel Analog Current Output (AO I) High Feature (HF)
Module Width	15 mm (ET 200S standard electronic module width)
Compatible Terminal Modules	TM-E15C26-A1, TM-E15C24-A1, TM-E15C24-01, TM-E15C23-01
Engineering Software	STEP 7 V5.x, TIA Portal (compatible with ET 200S configuration)
Product Status	Mature Manufacturer Status (replaced by newer generation)

Electrical Specifications

Supply Voltage (L+)	24 V DC (rated value)
Reverse Polarity Protection	Yes (for L+ supply)
Input Current from L+ (no load)	Max. 80 mA
Input Current from Backplane Bus (3.3 V DC)	Max. 10 mA
Power Loss	Max. 1.2 W
Address Space per Module	Max. 4 byte
Isolation	500 V DC (between channels and backplane bus/L+)

Analog Output Specifications

Number of Analog Outputs	2
Output Type	Current Output (I)
Output Ranges	-20 mA to +20 mA (15 bit+sign), 4 mA to 20 mA (15 bit)
Resolution (with overrange)	Max. 16 bit (including sign)
Cycle Time (all channels)	Max. 0.5 ms
Settling Time	0.3 ms (resistive load), 0.5 ms (inductive load), 1 ms (capacitive load)
No-Load Voltage (current output)	Max. 18 V
Load Impedance	Max. 500 Ω (resistive), Max. 1 mH (inductive)
Connection Type	Two-wire connection for current output (four-wire not supported)
Cable Length	Max. 200 m (shielded), 100 m if Twa < 2 ms
Destruction Limits	Max. 50 mA (externally applied current)

Accuracy & Error Specifications

Basic Error Limit (25 °C)	Current: (+/-) 0.05% of output range
Operational Error Limit (overall temp range)	Current: (+/-) 0.1% of output range

Diagnostic & Status Features

Diagnostic Information Readable
Wire-Break Detection (configurable)
Group Error Detection
Red SF (group fault) LED indicator
7 byte parameter space per module
Configurable response to CPU/Master STOP: output current de-energized, substitute value, or keep last value

Mechanical Specifications

Mounting Method	35 mm standard DIN rail mounting (TS 35/7.5, TS 35/15) via terminal module
Housing Material	Flame-retardant plastic (UL94 V-0)
Dimensions (W×H×D)	15 mm × 81 mm × 52 mm (0.59 in × 3.19 in × 2.05 in)
Net Weight	Approx. 40 g (0.09 lb)
Protection Rating	IP20 (when installed with terminal module)

Environmental Specifications

Operating Temperature	-25 °C to +60 °C (-13 °F to 140 °F)
Storage Temperature	-40 °C to +70 °C (-40 °F to 158 °F)
Relative Humidity	5% to 95% non-condensing (no dew formation)
Vibration Resistance	5 g (10-500 Hz), compliant with IEC 60068-2-6
Shock Resistance	15 g (11 ms half-sine), compliant with IEC 60068-2-27
Altitude Rating	0 to 2000 m (6562 ft) without derating
Pollution Degree	2 (per IEC 60664-1)
Overvoltage Category	II (per IEC 60664-1)

Certifications & Compliance

EMC Compliance	EN 61131-2, EN 61000-6-2, EN 61000-6-4
Safety Certification	CE, UL, cUL, RoHS Compliant
Industry Standards	IEC 61131-2 (industrial control equipment)

Key Functional Features

Isochronous Mode Support
Individual channel parameterization (output range, filter settings)
Hot swap capability for ET 200S electronic modules
Fully compliant with SIMATIC DP and ET 200S system standards
Real-time process data and diagnostic data transfer via PROFIBUS DP
